Nimonic 90 Pyromet 90 Udimet 90 High Temperature Aluminium Alloys

Name: Nimonic 90 Pyromet 90 Udimet 90 High Temperature Aluminium Alloys
Brand: Changzhou DLX Alloy Co., Ltd.
SKU: Nimonic 90
Price: 149.30 USD
Availability: InStock

Brand Name:	DLX
Model Number:	Nimonic 90
MOQ:	15
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	300 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001

Product Name:

Nimonic 90

Material:

Nickel Chromium

Density:

8.18g/cm³

Melting Point:

1370°C

Coefficient Of Expansion:

12.7 μm/m °C (20 – 100°C)

Modulus Of Rigidity:

82.5 KN/mm²

Modulus Of Elasticity:

213 KN/mm² 227 / 240 KN/mm²

Packaging Details:

Spool package with Carton box, Coil package with polybag

Supply Ability:

300 tons per month

Highlight:

Nimonic 90 High Temperature Aluminium Alloys

Pyromet 90 High Temperature Steel

Udimet 90 High Temperature Aluminium Alloys

Product Description

Nimonic 90 Pyromet 90 Udimet 90 High Temperature Aluminium Alloys 0

Nimonic 90high temperature nickel alloy

Nimonic 90 wire, A Nickel-Chromium-Cobalt alloy being precipitation hardenable, having high stress-rupture strength and creep resistance at high temperatures up to about 950^oC (1740^oF). It is widely used and a well proven alloy in high temperature conditions.

Nimonic 90 is also known as Superimphy 90, Pyromet 90, and Udimet 90.

Nimonic 90 wire Chemical Composition

The chemical composition of Nimonic 90 wire is given in the following table.

Element	Content (%)
Nickel, Ni	Bal
Chromium, Cr	18-21
Iron, Fe	≤1.5
Cobalt, Co	15-21
Titanium, Ti	2-3
Aluminum, Al	1.0-2.0
Manganese, Mn	≤1
Silicon	≤1
Others	Remainder

Nimonic 90 Physical Properties

The following table discusses the physical properties of Nimonic 90.

Properties	Metric	Imperial
Density	8.18 gm/cm3	0.296 lb/in3

Nimonic 90 Mechanical Properties

The mechanical properties of Nimonic 90 wire are tabulated below.

Properties
Condition	Approx. tensile strength		Approx. operating temperature depending on load^^ and environment
Condition	N/mm²	ksi	°C	°F
Annealed	800 – 1000	116 – 145	–	–
Annealed + Aged	1200 – 1400	174 – 203	up to 550	up to 1020
Spring Temper	1200 – 1500	175 – 218	–	–
Spring Temper + Aged	1500 – 1800	218 – 261	up to 350	up to 660
