Product Details
Place of Origin: China Jiangsu
Brand Name: DLX
Certification: CE,ROHS
Model Number: ni200 Pure Nickel
Payment & Shipping Terms
Minimum Order Quantity: 2kg
Price: $20-$300/kg
Packaging Details: Spool package with Carton box, Coil package with polybag,
Delivery Time: 5-20 Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500 tons per month
Product Name: |
Pure Nickel 200/201 |
Grade: |
200 201 N4 N6 |
Certificate: |
ISO9001 |
Material: |
Ni |
Elongation (≥ %):: |
35 |
Ni(min): |
99% |
Application:: |
Industry |
Melting Point: |
1435-1445℃ |
M.O.Q:: |
1KG |
Delivery: |
7-25 Days |
Shape: |
Wire |
Size: |
0.025-10mm |
Product Name: |
Pure Nickel 200/201 |
Grade: |
200 201 N4 N6 |
Certificate: |
ISO9001 |
Material: |
Ni |
Elongation (≥ %):: |
35 |
Ni(min): |
99% |
Application:: |
Industry |
Melting Point: |
1435-1445℃ |
M.O.Q:: |
1KG |
Delivery: |
7-25 Days |
Shape: |
Wire |
Size: |
0.025-10mm |
Nickel 201 is a commercially pure nickel with a maximum carbon level of 0.02%. This alloy provides highly ductile mechanical properties across a wide temperature range, and corrosion resistance in neutral to moderately reducing environments. It provides high thermal and electrical conductivity in comparison to nickel-base alloys, stainless and low alloy steels. With its lower carbon content, alloy 201 may be considered for service above 600°F (316°C), where alloy 200 with higher carbon content is not recommended.
| Grade | Chemical Composition(%) | ||||||||
| Ni+Co | Cu | Si | Mn | C | Mg | S | P | Fe | |
| N4/201 | 99.9 | ≤0.015 | ≤0.03 | ≤0.002 | ≤0.01 | ≤0.01 | ≤0.001 | ≤0.001 | ≤0.04 |
| N6/200 | 99.5 | 0.1 | 0.1 | 0.05 | 0.1 | 0.1 | 0.005 | 0.002 | 0.1 |
Wire: 0.025 to 8.0 mm.
Physical Data
| Density | 8.89g/cm3 |
| Specific Heat | 0.109(456 J/kg.℃) |
| Electrical Resistivity | 0.096×10-6ohm.m |
| Melting Point | 1435-1446℃ |
| Thermal Conductivity | 70.2 W/m-K |
| Mean Coeff Thermal Expansion | 13.3×10-6m/m.℃ |
Typical Mechanical Properties
| Mechanical Properties |
Nickel 201 |
| Tensile Strength | 462 Mpa |
| Yield Strength | 148 Mpa |
| Elongation | 47% |
Our Production Standard
| Bar | Forging | Pipe | Sheet/Strip | Wire | |
| ASTM | ASTM B160 | ASTM B564 | ASTM B161/B163/B725/B751 | AMS B162 |
ASTM B166 |
