Product Details:

Place of Origin: China
Brand Name: DLX
Model Number: ni200 Pure Nickel

Payment & Shipping Terms:

Minimum Order Quantity: 2kg
Price: $20-$300/kg
Packaging Details: Spool package with Carton box, Coil package with polybag,
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Get Best Price Contact Now

Detail Information

Product Name: Pure Nickel 200/201 Grade: 200 201 N4 N6
Certificate: ISO9001 Material: Ni
Elongation (≥ %):: 35 Ni(min): 99%
Application:: Industry Melting Point: 1435-1445℃
M.O.Q:: 1KG Delivery: 7-25 Days
Shape: Wire Size: 0.025-10mm
High Light:

Alloy 201 Pure Nickel Metal

,

0.025mm Pure Nickel Metal

,

Pure Nickel Wire For Mesh

Product Description

Alloy 201 Pure Nickel Metal Pure Nickel Wire 0.025mm For Mesh 0


Alloy 201 Pure Nickel Metal Pure Nickel Wire 0.025mm For Mesh


  • Pure Nickel Ni200/ Ni 201 wire

Nickel 201 is a commercially pure nickel with a maximum carbon level of 0.02%. This alloy provides highly ductile mechanical properties across a wide temperature range, and corrosion resistance in neutral to moderately reducing environments. It provides high thermal and electrical conductivity in comparison to nickel-base alloys, stainless and low alloy steels. With its lower carbon content, alloy 201 may be considered for service above 600°F (316°C), where alloy 200 with higher carbon content is not recommended.

Alloy 201 Pure Nickel Metal Pure Nickel Wire 0.025mm For Mesh 1Alloy 201 Pure Nickel Metal Pure Nickel Wire 0.025mm For Mesh 2



Grade Chemical Composition(%)
Ni+Co Cu Si Mn C Mg S P Fe
N4/201 99.9 ≤0.015 ≤0.03 ≤0.002 ≤0.01 ≤0.01 ≤0.001 ≤0.001 ≤0.04
N6/200 99.5 0.1 0.1 0.05 0.1 0.1 0.005 0.002 0.1






  • Size range

Wire: 0.025 to 8.0 mm.



Physical Data

Density 8.89g/cm3
Specific Heat 0.109(456 J/kg.℃)
Electrical Resistivity 0.096×10-6ohm.m
Melting Point 1435-1446℃
Thermal Conductivity 70.2 W/m-K
Mean Coeff Thermal Expansion 13.3×10-6m/m.℃

Typical Mechanical Properties

Mechanical Properties

Nickel 201

Tensile Strength 462 Mpa
Yield Strength 148 Mpa
Elongation 47%

Our Production Standard

  Bar Forging Pipe Sheet/Strip Wire
ASTM ASTM B160 ASTM B564 ASTM B161/B163/B725/B751 AMS B162

ASTM B166



Alloy 201 Pure Nickel Metal Pure Nickel Wire 0.025mm For Mesh 3
