Electrical Connections Thermal Stability Pure Nickel Wire

Name: Electrical Connections Thermal Stability Pure Nickel Wire
Brand: Changzhou DLX Alloy Co., Ltd.
SKU: pure nickel wire
Price: 160.00 USD
Availability: InStock

Brand Name:	DLX
Model Number:	pure nickel wire
MOQ:	2kg
Price:	$20-$300/kg
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China Jiangsu

Certification:

CE,ROHS

Product Name:

Pure Nickel Wire

Grade:

200 201 N4 N6

Certificate:

ISO9001

Material:

Elongation (≥ %)::

Ni(min):

99.6%

Application::

Industry

Melting Point:

1435-1445℃

M.O.Q::

1KG

Delivery:

7-25 Days

Shape:

Wire

Size:

0.025-10mm

Packaging Details:

Spool package with Carton box, Coil package with polybag for pure nickel wire 0.025mm

Supply Ability:

500 tons per month

Highlight:

Electrical Connections Pure Nickel Wire

Thermal Stability Nickel Wire

Thermal Stability Pure Nickel Wire

Product Description

Electrical Connections Thermal Stability Pure Nickel Wire

Pure nickel alloy

Trust in the durability and performance of our pure nickel wire, engineered for excellence in a wide range of applications. With its high melting point and resistance to oxidation, this wire is ideal for use in high-temperature environments such as furnace heating elements and thermocouples. Its excellent electrical conductivity and low coefficient of thermal expansion ensure efficient energy transfer and accurate temperature measurements, making it an essential component in demanding industrial processes.

Grade	Chemical Composition(%)
Grade	Ni+Co	Cu	Si	Mn	C	Mg	S	P	Fe
N4/201	99.9	≤0.015	≤0.03	≤0.002	≤0.01	≤0.01	≤0.001	≤0.001	≤0.04
N6/200	99.5	0.1	0.1	0.05	0.1	0.1	0.005	0.002	0.1

Physical Data

Size Range	0.025 to 8.0 mm
Density	8.89g/cm3
Specific Heat	0.109(456 J/kg.℃)
Electrical Resistivity	0.096×10-6ohm.m
Melting Point	1435-1446℃
Thermal Conductivity	70.2 W/m-K
Mean Coeff Thermal Expansion	13.3×10-6m/m.℃
Tensile Strength	462 Mpa
Yield Strength	148 Mpa
Elongation	47%

Production Process

1. Nickel ore extraction: Nickel is extracted from nickel ore through mining and processing.

2. Nickel refining: The extracted nickel is refined to remove impurities and achieve high purity.

3. Nickel melting: The refined nickel is melted in a furnace to form a molten nickel alloy.

4. Wire drawing: The molten nickel alloy is then drawn through a series of dies to reduce its diameter and form a continuous wire.

5. Annealing: The nickel wire is annealed to relieve internal stresses and improve its ductility.

6. Surface treatment: The nickel wire may undergo surface treatment processes such as cleaning, coating, or plating to enhance its properties or appearance.

7. Quality control: The final nickel wire product is inspected and tested to ensure it meets the required specifications before packaging and distribution.

Electrical Connections Thermal Stability Pure Nickel Wire 1
