Product Details:

Place of Origin: China
Brand Name: DLX
Model Number: ni200 Pure Nickel

Payment & Shipping Terms:

Minimum Order Quantity: 2kg
Price: $20-$300/kg
Packaging Details: Spool package with Carton box, Coil package with polybag,
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Get Best Price Contact Now

Detail Information

Product Name: Pure Nickel 200/201 Grade: 200 201 N4 N6
Certificate: ISO9001 Material: Ni
Elongation (≥ %):: 35 Ni(min): 99%
Application:: Industry Melting Point: 1435-1445℃
M.O.Q:: 1KG Delivery: 7-25 Days
Shape: Wire Size: 0.025-10mm
High Light:

ASTM B166 Pure Nickel Metal

,

UNS N02200 Pure Nickel

,

0.025mm Pure Nickel Metal

Product Description

ASTM B166 Ni201 UNS N02200 0.025mm Pure Nickel Metal 0





  • Pure Nickel Ni200/ Ni 201 wire

Commercially wrought pure nickel ( UNS N02200) , a grade of pure nickel contains 99.2% nickel, has excellent mechanical properties,

magnetic properties, high thermal, electrical conductivity and excellent resistance to many corrosive environment.

Pure nickel  is useful in any environment below 600℉(315℃).

It has highly resistance to neutral and alkaline salt solutions.

Pure nickel  also has low corrosion rates in neutral and distilled water .

The applications of pure nickel  includes food processing equipment, magnetostrictive devices and

rechargeable batteries, computers, cellular Phone, power tools, camcorders and so on.ASTM B166 Ni201 UNS N02200 0.025mm Pure Nickel Metal 1



Grade Chemical Composition(%)
Ni+Co Cu Si Mn C Mg S P Fe
N4/201 99.9 ≤0.015 ≤0.03 ≤0.002 ≤0.01 ≤0.01 ≤0.001 ≤0.001 ≤0.04
N6/200 99.5 0.1 0.1 0.05 0.1 0.1 0.005 0.002 0.1






  • Size range

Wire: 0.025 to 8.0 mm.



Physical Data

Density 8.89g/cm3
Specific Heat 0.109(456 J/kg.℃)
Electrical Resistivity 0.096×10-6ohm.m
Melting Point 1435-1446℃
Thermal Conductivity 70.2 W/m-K
Mean Coeff Thermal Expansion 13.3×10-6m/m.℃

Typical Mechanical Properties

Mechanical Properties Nickel 200
Tensile Strength 462 Mpa
Yield Strength 148 Mpa
Elongation 47%

Our Production Standard

  Bar Forging Pipe Sheet/Strip Wire
ASTM ASTM B160 ASTM B564 ASTM B161/B163/B725/B751 AMS B162

ASTM B166
