Nimonic C 263 5120 Haynes 263 High Temperature Nickel Alloy

Name: Nimonic C 263 5120 Haynes 263 High Temperature Nickel Alloy
Brand: Changzhou DLX Alloy Co., Ltd.
SKU: Nimonic C-263
Price: 149.30 USD
Availability: InStock

Brand Name:	DLX
Model Number:	Nimonic C-263
MOQ:	15
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	300 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001

Product Name:

Nimonic C-263

Material:

Nickel Chromium

Density:

8.36g/cm³

Melting Point:

1325 °C

Coefficient Of Expansion:

10.6 μm/m• °C (20 – 100 °C)

Modulus Of Elasticity:

222.5 KN/mm²

Packaging Details:

Spool package with Carton box, Coil package with polybag

Supply Ability:

300 tons per month

Highlight:

Nimonic C 263 High Temperature Nickel Alloy

ISO 9001 High Temperature Steel Alloys

Haynes 263 High Temperature Nickel Alloy

Product Description

Nimonic C 263 5120 Haynes 263 High Temperature Nickel Alloy 0

Nimonic C-263 High Temperature Nickel Alloy

Nimonic C-263 is a nickel-chromium-cobalt-molybdenum alloy specially meant for use in high temperature and high strength applications. This alloy can be precipitation-hardened

Nimonic C-263 is also known as Nicrofer 5120 CoTi, Haynes 263, and Hastelloy C-263.

Nimonic C-263 Chemical Composition

The chemical composition of Nimonic C-263 is given in the following table.

Element	Content (%)
Nickel, Ni	Bal
Chromium, Cr	19-21
Iron, Fe	≤0.7
Cobalt, Co	19-21
Titanium, Ti	1.9-2.4
Aluminum, Al	≤0.6
Manganese, Mn	≤0.6
Silicon,Si	≤0.4
Molybdenum,Mo	5.6-6.1
Others	Remainder

Nimonic C-263 Physical Properties

The following table discusses the physical properties of Nimonic C-263.

Properties	Metric	Imperial
Density	8.36gm/cm3	0.302 lb/in3

Nimonic C-263 Mechanical Properties

The mechanical properties of Nimonic C-263 are tabulated below.

PROPERTIES
Condition	Approx. tensile strength		Approx. operating temperature depending on load and environment
Condition	N/mm²	ksi	°C	°F
Annealed	800 – 1000	116 – 145	up to 800	up to 1500
Annealed + Aged	1000 – 1200	145 – 174	up to 800	up to 1500
Spring Temper	1200 – 1500	174 – 217	up to 800	up to 1500
Spring Temper + Annealed + Aged	1000 – 1200	145 – 174	up to 800	up to 1500
