One Plate Family for Battery Assembly & Industrial Equipment

Battery assembly and industrial equipment run on different clocks: a battery line moves fast and measures resistance per milliohm, an equipment shop fabricates to drawings and measures fit. Both buy the same material family — pure nickel plate — and both depend on the supplier being flexible enough to serve them. DLX supplies pure nickel plate for both scenarios: four grades (N4, N6, Ni200, Ni201), M/1/4H/1/2H tempers, and any grade-temper combination on a single order, from 5 kg trial quantities to container volumes. Resistivity is 0.096 μΩ·m at 20°C, sizes are customized per drawing from 0.05-30mm thick, and every plate carries EN 10204 3.1 MTC with heat traceability.

• One plate family for two scenarios — battery assembly & industrial equipment.
• Grade * temper combinations on a single order — match the material state to the part.
• Flexible supply — 5 kg trial minimums up to container volumes.
• Low resistance — 0.096 μΩ·m at 20°C for efficient battery connections.
• Customized sizes with EN 10204 3.1 MTC on every plate.

The same plate family serves two very different shop floors. Battery assembly uses plate for cell connection components and busbars, where low resistance and precise forming dominate. Industrial equipment uses plate for machined parts, structures and welded assemblies, where strength and corrosion resistance dominate. The grade and temper are selected per scenario — the material family stays the same, the material state changes.

Selection is a combination, not a single choice. Form a battery part from N6 in M temper for formability; build an industrial structure from Ni200 in 1/2H for strength; serve high-temperature duty with Ni201; reserve N4 (NP1) for the strictest purity. Any combination ships on one order with one documentation standard.

Plate is made to order: thickness 0.05-30mm, width 20-1000mm and length 1200-2000mm, confirmed per drawing before production — so battery and industrial buyers order the size they fabricate, not a stock size they rework.

The annealed baseline is documented per heat — ≥462 MPa tensile strength, ≥35% elongation and 90-120 HB hardness — while resistivity sits at 0.096 μΩ·m at 20°C with thermal conductivity of 70.2 W/m·K for Ni200. One data sheet serves both shop floors.

Indicative FOB China reference prices for plate; final quotation per grade, size, quantity and temper.

Source: DLX product catalog. N4/N6 per GB system; Ni200/Ni201 per ASTM system.

The 5 kg minimum applies to pure nickel plate; other forms follow the grade-based schedule (wire 1/5 kg, strip 5 kg, bar/pipe 10 kg).

Quality control for plate follows the form, not a generic checklist:

• Incoming: raw nickel verified per heat before processing.
• In-process: thickness, width and surface checked; flatness inspected; temper verified per batch.
• Final: chemistry verified per heat; tensile and hardness sampled per heat.
• Documentation: EN 10204 3.1 MTC with heat number, test results and full traceability.

Ni200/Ni201 plate is manufactured and tested to ASTM B162; N4/N6 follow GB/T 2054-2023. Testing methods and acceptance criteria follow the drawing specification and applicable standards.

Plates are packed with protective sheets and shipped in wooden cases to prevent surface damage in transit. Production lead time is 7-15 days after drawing and grade confirmation. Every order ships with the complete export documentation set: packing list, commercial invoice and mill test certificate.

Supply flexibility is a production capability, not a promise. Changzhou DLX Alloy Co., Ltd. supports both battery assembly lines and industrial equipment makers with one plate family: multiple grades and tempers on a single order, 5 kg minimums for trial runs, and sizes confirmed per drawing on a nickel-only 12,000 m² line operating since 2002. Every combination ships with EN 10204 3.1 MTC, so dual-scenario buyers qualify once and order what they need — from sample quantities to container volumes.

Battery assembly uses plate for low-resistance, precisely formed connection components; industrial equipment uses it for strong, corrosion-resistant machined parts — the grade and temper are selected per scenario on the same material family.

Yes — any combination of N4/N6/Ni200/Ni201 and M/1/4H/1/2H can ship on a single order with one documentation standard.

Thickness 0.05-30mm, width 20-1000mm and length 1200-2000mm, customized per drawing before production.

5 kg for trial quantities, up to container volumes — flexible supply for both battery and industrial buyers.

Every delivery includes EN 10204 3.1 MTC with heat number and batch traceability, backed by ISO9001 and SGS certification. Plate meets ASTM B162 (Ni200/Ni201) and GB/T 2054-2023 (N4/N6).
