| Brand Name: | DLX |
| Model Number: | Pure Nickel wire 0.025mm |
| MOQ: | 2kg |
| Payment Terms: | L/C,T/T,Western Union |
| Supply Ability: | 500 tons per month |
Best Price Nickel Wire 0.025mm For Russia
Pure nickel wire is a highly versatile and durable wire that is composed solely of nickel metal. It is known for its exceptional resistance to corrosion, making it an excellent choice for applications in harsh environments.
easy to degas, suitable for radio, electric light source, machinery manufacturing, chemical industry, and is an important vacuum electronic device. of structural materials
| Grade | N4 | N6 | Nickel 201 | Nickel 200 | |
| Ni | -- | -- | ≥99 | ≥99.2 | |
| Ni+Co | 99.9 | 99.5 | -- | -- | |
| Cu | ≤0.015 | 0.1 | ≤0.25 | ≤0.25 | |
| Si | ≤0.03 | 0.1 | ≤0.35 | ≤0.35 | |
| Mn | ≤0.002 | ≤0.350.05 | ≤0.35 | ≤0.35 | |
| C | ≤0.01 | 0.1 | ≤0.02 | ≤0.15 | |
| Mg | ≤0.01 | 0.1 | -- | -- | |
| S | ≤0.001 | 0.005 | ≤0.01 | ≤0.01 | |
| P | ≤0.001 | 0.002 | -- | -- | |
| Fe | ≤0.04 | ||||
Wire: 0.025 to 8.0 mm.
| Density | 8.89g/cm3 |
| Specific Heat | 0.109(456 J/kg.℃) |
| Electrical Resistivity | 0.096*10-6ohm.m |
| Melting Point | 1435-1446℃ |
| Thermal Conductivity | 70.2 W/m-K |
| Mean Coeff Thermal Expansion | 13.3*10-6m/m.℃ |
| Mechanical Properties | Nickel 200 |
| Tensile Strength | 462 Mpa |
| Yield Strength | 148 Mpa |
| Elongation | 47% |
