Product Details
Place of Origin: China
Brand Name: DLX
Model Number: ErNiFe-6
Payment & Shipping Terms
Minimum Order Quantity: 15
Packaging Details: Spool package with Carton box, Coil package with polybag
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Material: |
Ni. Cr. Fe. Mn. Ti |
Elongation: |
≥30% |
Tensile Strength Rm N/mm²: |
560mpa |
Grade: |
ASME SFA 5.14 ErNiFe-6 |
Melting Point: |
1320-1370℃ |
Certificate: |
ISO 9001 |
Material: |
Ni. Cr. Fe. Mn. Ti |
Elongation: |
≥30% |
Tensile Strength Rm N/mm²: |
560mpa |
Grade: |
ASME SFA 5.14 ErNiFe-6 |
Melting Point: |
1320-1370℃ |
Certificate: |
ISO 9001 |
AWS A5.14 1.6mm ErNiFe-6 incoloy alloy filling wire from manufacturer
Nickel Based Welding Wire
Nickel based welding wire ERNiCrFe-6 is a nickel-based filler metal for welding. Changzhou DLX alloy is one of the main producer in China for the ErNiCrFe-6 welding wire. ErNiCrFe properties are appropriate for the as-welded condition. Also ERNiCrFe-6 is the AWS designation for this material. N07092 is the UNS number.ErNiCrFe-6 also has a moderately low base cost among nickel-based welding fillers. In addition, it has a moderately low embodied energy and a moderately low melting temperature.The graph bars on the material properties cards below compare AWS ERNiCrFe-6 to: nickel-based welding fillers (top), all nickel alloys (middle), and the entire database (bottom). A full bar means this is the highest value in the relevant set. A half-full bar means it's 50% of the highest, and so on.
Nickel alloy Weling wire series:
ERNiCrMo-3,ERNiCrMo-4,ERNiCrMo-13,ERNiCrFe-3,ERNiCrFe-7,ERNiCr-3,ERNiCr-7,ERNiCu-7,ERNi-1, ER70S-6.
Standard: Conforms to Certification AWS A5.14 ASME SFA A5.14
Size: 0.8MM / 1.0MM / 1.2MM / 1.6MM / 2.4MM / 3.2MM / 3.8MM / 4.0MM / 5.0MM
Form: MIG(15kgs/spool), TIG(5kgs/box),Strip
Nickel welding wire Nickel welding wire Nickel welding wire Nickel welding wire Nickel welding wire
| Ni+Co | Cr | Fe | Cu | Ti | Mn | Si | S | P | C | Others |
| 67 Min | 14-17 | 8 max | 0.5 max. | 2.5-3.5. | 2-2.7 | 0.35max | 0.015 max. | 0.03 Max | 0.08 max. | 0.5 Max |
Size we could offer
| MIG | (15kg/spool), | Size |
| 0.8 1.2 2.4 3.2mm | ||
| TIG | (5kg/box),Strip |
Application
ErNiCrFe-6 Filler Metal 92 is used for gas-tungsten-arc and gas-metal-arc welding of austenitic and ferritic steels and nickel alloys. Applications include joining INCONEL and INCOLOY alloys to stainless steels, carbon steels, and MONEL alloys; joining MONEL alloys and Nickel 200 to stainless steels; and joining stainless steels to carbon steels. The filler metal is also used for welding nickel steels. Filler Metal 92 provides high strength and corrosion resista nee at temperatures ranging from the cryogenic region to over 1800°F (980°C). Weld deposits can be age hardened for greater strength at temperatures to about 1300°F (700°C).
CHANGZHOU DLX ALLOY COMPANY was establish in 2016,our factory established in 2002 and has got ISO9001 International Quality Management System Certificate and SGS Certificate.Our factory is becoming a high-tech company,We are professional in researching and producing special alloy material.The production process include melting,drawing,heat treatment,finishing and testing.We offer super alloy,welding wire,corrosion resistance alloy,precision alloy,FeCrAl alloy,NiCr alloy,CuNi alloy,in the form of wire,strip,ribbon,bar,tube,plate and etc.The administrative principle of our company is "intensifying inner supervision, complying with technical process and quality control, continuously adopting new technology to ensure the product quality". We employ some senior engineers to instruct technology, apply new technology and research new products. Our operation principle is "Quality first, Customer first". All the staff of our company would like to provide high quality and reasonably priced products for clients at home and abroad, and to make your products more competitive.
