AWS A5.14 Certified Nickel Welding Wire with 1320-1370℃ Melting Point and ≥30% Elongation for Monel 400 NO5500

Name: AWS A5.14 Certified Nickel Welding Wire with 1320-1370℃ Melting Point and ≥30% Elongation for Monel 400 NO5500
Brand: Changzhou DLX Alloy Co., Ltd.
SKU: ErNiCu 7
Price: 37.00 USD
Availability: InStock

Brand Name:	DLX
Model Number:	ErNiCu 7
MOQ:	15
Price:	Negotiable
Payment Terms:	L/C,T/T,Western Union,MoneyGram
Supply Ability:	300 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Material:

Nickel,Copper. Ti

Elongation:

≥30 %

Density:

8.7 G/cm3

Tensile Strength Rm N/mm²:

75,000 PSI

Yieldstrength R P0. 2 N/mm²:

52,000 PSI

Melting Point:

1320-1370℃

Certificates:

AWS A5.14 / ASME SFA A5.14

Packaging Details:

Spool package with Carton box, Coil package with polybag

Supply Ability:

300 tons per month

Highlight:

ErNiCu 7 Nickel Welding Wire

Monel 400 Nickel Base Alloy

NO5500 Nickel Welding Wire

Product Description

AWS A5.14 ErNiCu 7 Monel 400 NO5500 Nickel Welding Wire

Nickel Based Welding Wire

ERNiCu-7 is a copper-nickel alloy base wire for GMAW and GTAW welding of Monel alloys 400 and 404. Also used for overlaying steel after first applying Layer of 610 nickel.

It is used for joining base materials such as UNS number NO4400, NO4405 and NO5500. This alloy can be used for dissimilar welding applications using various nickel-copper alloys to nickel 200 and to copper-nickel alloys. This can be used for MIG overlay on steel after a first layer with nickel 208.

Welding Series

ERNiCrMo-3
ERNiCrMo-4
ERNiCrMo-13
ERNiCrFe-3
ERNiCrFe-7
ERNiCr-3
ERNiCr-7
ERNiCu-7
ERNi-1
ER70S-6

Specifications

Standard: Conforms to Certification AWS A5.14 ASME SFA A5.14
Size: 0.8MM / 1.0MM / 1.2MM / 1.6MM / 2.4MM / 3.2MM / 3.8MM / 4.0MM / 5.0MM
Form: MIG(15kgs/spool), TIG(5kgs/box), Strip

Chemical Properties of ErNiCu-7

Item	C	Mn	Fe	P	S	Si	Cu	Ni	Co	Al	Ti	Cr	Nb+Ta	Mo	V	W	Rest
ERNiCu-7	0.15	4	2.5	0.02	0.015	1.25	rest	62-69	N/A	1.25	1.5-3	N/A	N/A	N/A	N/A	N/A	≤0.50

Available Sizes

Type	Packaging	Size
MIG	(15kg/spool)	0.8, 1.2, 2.4, 3.2mm
TIG	(5kg/box), Strip
