ASME SFA A5.14 ERNiCrMo 13 1.6mm Nickel Welding Wire

Product Details

Place of Origin: China

Brand Name: DLX

Model Number: ERNiCrMo-13

Payment & Shipping Terms

Minimum Order Quantity: 15

Packaging Details: Spool package with Carton box, Coil package with polybag

Delivery Time: 5-21 days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 300 tons per month

Get Best Price
Contact Now
Specifications
Highlight:

ASME SFA A5.14 Nickel Welding Wire

,

ERNiCrMo 13 Aluminum Chromium Alloy

,

1.6mm Nickel Welding Wire

Material:
Ni, Mo, Cr
Elongation:
≥22 %
Density:
8.60 G/cm3
Tensile Strength Rm N/mm²:
≥600
Yieldstrength R P0. 2 N/mm²:
≥360
Melting Point:
1310-1360℃
Certificates:
AWS A5.14 / ASME SFA A5.14
Material:
Ni, Mo, Cr
Elongation:
≥22 %
Density:
8.60 G/cm3
Tensile Strength Rm N/mm²:
≥600
Yieldstrength R P0. 2 N/mm²:
≥360
Melting Point:
1310-1360℃
Certificates:
AWS A5.14 / ASME SFA A5.14
Description
ASME SFA A5.14 ERNiCrMo 13 1.6mm Nickel Welding Wire

ASME SFA A5.14 ERNiCrMo 13 1.6mm Nickel Welding Wire 0


ASME SFA A5.14 ERNiCrMo 13 1.6mm Nickel Welding Wire 1


  • Nickel Based Welding Wire

Nickel alloy welding wire ERNiCrMo-13 is a nickel-chromium-molybdenum alloy with extra low carbon and silicon contents. It offers excellent corrosion resistance, high mechanical strength, and better thermal stability. Because of its low silicon and carbon contents and no tungsten, Pinnacle Alloys ERNiCrMo-13 is not prone to grain-boundary precipitation during hot forming and welding. Pinnacle Alloys ERNiCrMo-13 is well suited for welding in a wide variety of chemical processing facilities in both oxidizing and reducing media. This wire provides exceptional weldability and very low sensitivity to hot cracking.

It is designed to match the nickel base alloy commonly known as alloy 59. The high level of Mo is similar to alloys C276 but performance in a wide range of more oxidising media is significantly enhanced in alloy 59 by increasing Cr to 23%. This alloy also provides a tough Nb-free weld metal for dissimilar welds in superaustenitic and superduplex stainless steel or combinations of these with Ni base alloys.


Nickel alloy Weling wire series:
ERNiCrMo-3,ERNiCrMo-4,ERNiCrMo-13,ERNiCrFe-3,ERNiCrFe-7,ERNiCr-3,ERNiCr-7,ERNiCu-7,ERNi-1, ER70S-6.

Standard: Conforms to Certification AWS A5.14 ASME SFA A5.14

Size: 0.8MM / 1.0MM / 1.2MM / 1.6MM / 2.4MM / 3.2MM / 3.8MM / 4.0MM / 5.0MM

Form: MIG(15kgs/spool), TIG(5kgs/box),Strip

Nickel welding wire    Nickel welding wire    Nickel welding wire   Nickel welding wire   Nickel welding wire


  • Chemical Properties of Nickel welding wire ERNiCrMo-13

  •
  •

    C Mn Si Fe S P Cu Al Co Ni Cr Mo
    max 0.01 max 0.5 max 0.5 max 1.5 max 0.01 max 0.015 max 0.5 0.1-0.4 max 0.3 Balance 22-24 15.0-16.5




Nickel Welding Wire    Nickel Welding Wire    Nickel Welding Wire   Nickel Welding Wire




  • Size we could offer



MIG (15kg/spool), Size
    0.8 1.2 2.4 3.2mm
TIG (5kg/box),Strip





ASME SFA A5.14 ERNiCrMo 13 1.6mm Nickel Welding Wire 2
