Product Details:

Place of Origin: China
Brand Name: DLX
Model Number: Hastelloy C-4

Payment & Shipping Terms:

Minimum Order Quantity: 5
Packaging Details: Hastelloy C-4 wire packed in spool,in coil,then in carton,in woodencase
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Get Best Price Contact Now

Detail Information

Material: Ni Cr Mo Elongation: 30 %
Brinell Hardness HB: ≤220 Density: 8.89 G/cm3
Tensile Strength Rm N/mm²: 760MPA Yieldstrength R P0. 2 N/mm²: 345MPA
Electrical Resistivity(24℃)): 1.30 Microhm-m Thermal Conductivity(32℃): 9.4 W/m-K
Model Number: Bright Soft Nickel Based Alloy Hastelloy C-4 Alloy Wire With Good Price
High Light:

Acetic Anhydride Hastelloy Alloy

,

C4 Nickel Chromium Molybdenum Steel

,

Soft Hastelloy Alloy

Product Description

Acetic Anhydride 345MPA C4 N06455 Soft Hastelloy Alloy 0


Acetic Anhydride 345MPA C4 N06455 Soft Hastelloy Alloy 1


  • Nickel Based corrosion resistance Alloy

HASTELLOY® C-4 alloy (UNS N06455) is the most (microstructurally) stable of the widely used nickel-chromium-molybdenum materials, which are well known for their resistance to many aggressive chemicals, in particular hydrochloric acid, sulfuric acid, and chlorides. This stability means that the alloy can be welded without fear of sensitization, i.e. the nucleation and growth of deleterious, second phase precipitates in the grain boundaries of the weld heat-affected zone (HAZ).

Like other nickel alloys, it is ductile, easy to form and weld, and possesses exceptional resistance to stress corrosion cracking in chloride-bearing solutions (a form of degradation to which the austenitic stainless steels are prone). With its high chromium and molybdenum contents, it is able to withstand both oxidizing and non-oxidizing acids, and is resistant to pitting and crevice attack in the presence of chlorides and other halides.








  • Chemical Properties of Hastelloy C-4 Wire

Hastelloy Alloy Ni Cr Co Mo FE W Mn C V P S Si
C-4 Balance 14-18 2 Max 14-17 3.0 Max   1.0 Max 0.015 Max   0.04 Max 0.03 Max 0.08 Max








  • Application


Some typical applications are:

  • Strong oxidizers (such as ferric and cupric chlorides)
  • Hot contaminated media (organic and inorganic)
  • Chlorine
  • Formic and acetic acids
  • Acetic anhydride
  • Seawater and brine solutions






  • Type we could offer
ASTM Alloy Type UNS Misc./Shape
ASTM B574
Bar
Hastelloy C-4 Nickel N06455 Bar Acetic Anhydride 345MPA C4 N06455 Soft Hastelloy Alloy 2
ASTM B575
Plate
Hastelloy C-4 Nickel N06455 Plate Acetic Anhydride 345MPA C4 N06455 Soft Hastelloy Alloy 3
ASTM B575
Strip
Hastelloy C-4 Nickel N06455 Strip Acetic Anhydride 345MPA C4 N06455 Soft Hastelloy Alloy 4
ASTM B575
Sheet
Hastelloy C-4 Nickel N06455 Sheet Acetic Anhydride 345MPA C4 N06455 Soft Hastelloy Alloy 5
ASTM B619
Welded Pipe
Hastelloy C-4 Nickel N06455 Welded Pipe Acetic Anhydride 345MPA C4 N06455 Soft Hastelloy Alloy 6
ASTM B622
Seamless Tubing
Hastelloy C-4 Nickel N06455 Seamless Tubing Acetic Anhydride 345MPA C4 N06455 Soft Hastelloy Alloy 7 Acetic Anhydride 345MPA C4 N06455 Soft Hastelloy Alloy 8
ASTM B366
Fittings
Hastelloy C-4 Nickel N06455 Fittings Acetic Anhydride 345MPA C4 N06455 Soft Hastelloy Alloy 9
ASTM B574
Wire
Hastelloy C-4 Nickel N06455 Wire
