Product Details
Place of Origin: China
Brand Name: DLX
Model Number: Hastelloy C276 Tube
Payment & Shipping Terms
Minimum Order Quantity: 5
Packaging Details: Hastelloy C276 Tube packed in wooden case
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Material: |
Ni Cr Mo |
Elongation: |
30 % |
Brinell Hardness HB: |
≤220 |
Density: |
8.89 G/cm3 |
Tensile Strength Rm N/mm²: |
760MPA |
Yieldstrength R P0. 2 N/mm²: |
345MPA |
Electrical Resistivity（24℃））: |
1.30 Microhm-m |
Thermal Conductivity（32℃）: |
9.4 W/m-K |
Product Name: |
Hot Sale Industry Bright Annealing Hastelloy C276 Nickel Alloy Hastelloy C276 Round Tube |
Material: |
Ni Cr Mo |
Elongation: |
30 % |
Brinell Hardness HB: |
≤220 |
Density: |
8.89 G/cm3 |
Tensile Strength Rm N/mm²: |
760MPA |
Yieldstrength R P0. 2 N/mm²: |
345MPA |
Electrical Resistivity（24℃））: |
1.30 Microhm-m |
Thermal Conductivity（32℃）: |
9.4 W/m-K |
Product Name: |
Hot Sale Industry Bright Annealing Hastelloy C276 Nickel Alloy Hastelloy C276 Round Tube |
Hastelloy C276 Tube UNS N10276) was the first wrought, nickel-chromium-molybdenum material to alleviate concerns over welding (by virtue of extremely low carbon and silicon contents). As such, it was widely accepted in the chemical process and associated industries, and now has a more than 50-year-old track record of proven performance in a vast number of corrosive chemicals.
Like other nickel alloys, it is ductile, easy to form and weld, and possesses exceptional resistance to stress corrosion cracking in chloride-bearing solutions (a form of degradation to which the austenitic stainless steels are prone). With its high chromium and molybdenum contents, it is able to withstand both oxidizing and non-oxidizing acids, and exhibits outstanding resistance to pitting and crevice attack in the presence of chlorides and other halides. Furthermore, it is very resistant to sulfide stress cracking and stress corrosion cracking in sour, oilfield environments
| Hastelloy Alloy | Ni | Cr | Co | Mo | FE | W | Mn | C | V | P | S | Si |
| C276 | Balance | 14.5-16.5 | 2.5 Max | 15.0-17.0 | 4.0-7.0 | 3.0-4.5 | 1.0 Max | 0.01 Max | 0.35 Max | 0.04 Max | 0.03 Max | 0.08 Max |
Some typical applications are:
| ASTM | Alloy | Type | UNS | Misc./Shape | |
| ASTM B574 Bar |
Hastelloy C276 | Nickel | N10276 | Bar | |
| ASTM B575 Plate |
Hastelloy C276 | Nickel | N10276 | Plate | |
| ASTM B575 Strip |
Hastelloy C276 | Nickel | N10276 | Strip | |
| ASTM B575 Sheet |
Hastelloy C276 | Nickel | N10276 | Sheet | |
| ASTM B619 Welded Pipe |
Hastelloy C276 | Nickel | N10276 | Welded Pipe | |
| ASTM B622 Seamless Tubing |
Hastelloy C276 | Nickel | N10276 | Seamless Tubing | |
| ASTM B366 Fittings |
Hastelloy C276 | Nickel | N10276 | Fittings | |
| ASTM B574 Wire |
Hastelloy C276 | Nickel | N10276 | Wire |
