Product Details:

Place of Origin: China
Brand Name: DLX
Model Number: Hastelloy C276

Payment & Shipping Terms:

Minimum Order Quantity: 5
Packaging Details: Spool package with Carton box, Coil package with polybag
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Get Best Price Contact Now

Detail Information

Material: Ni Cr Mo Elongation: 30 %
Brinell Hardness HB: ≤220 Density: 8.89 G/cm3
Tensile Strength Rm N/mm²: 760MPA Yieldstrength R P0. 2 N/mm²: 345MPA
Electrical Resistivity(24℃)): 1.30 Microhm-m Thermal Conductivity(32℃): 9.4 W/m-K
High Light:

Hastelloy C276 Nickel Chromium Molybdenum

,

UNS N10276 Chromium Molybdenum

,

B574 Nickel Chromium Molybdenum

Product Description

Hastelloy C276 UNS N10276 B574 Nickel Chromium Molybdenum 0


Hastelloy C276 UNS N10276 B574 Nickel Chromium Molybdenum 1


  • Nickel Based corrosion resistance Alloy

HASTELLOYC-276 UNS N10276) was the first wrought, nickel-chromium-molybdenum material to alleviate concerns over welding (by virtue of extremely low carbon and silicon contents). As such, it was widely accepted in the chemical process and associated industries, and now has a more than 50-year-old track record of proven performance in a vast number of corrosive chemicals.

Like other nickel alloys, it is ductile, easy to form and weld, and possesses exceptional resistance to stress corrosion cracking in chloride-bearing solutions (a form of degradation to which the austenitic stainless steels are prone). With its high chromium and molybdenum contents, it is able to withstand both oxidizing and non-oxidizing acids, and exhibits outstanding resistance to pitting and crevice attack in the presence of chlorides and other halides. Furthermore, it is very resistant to sulfide stress cracking and stress corrosion cracking in sour, oilfield environments








  • Chemical Properties of Hastelloy C276

Hastelloy Alloy Ni Cr Co Mo FE W Mn C V P S Si
C276 Balance 14.5-16.5 2.5 Max 15.0-17.0 4.0-7.0 3.0-4.5 1.0 Max 0.01 Max 0.35 Max 0.04 Max 0.03 Max 0.08 Max








  • Application


Some typical applications are:

  • Strong oxidizers (such as ferric and cupric chlorides)
  • Hot contaminated media (organic and inorganic)
  • Chlorine
  • Formic and acetic acids
  • Acetic anhydride
  • Seawater and brine solutions






  • Type we could offer
ASTM Alloy Type UNS Misc./Shape
ASTM B574
Bar
Hastelloy C276 Nickel N10276 Bar Hastelloy C276 UNS N10276 B574 Nickel Chromium Molybdenum 2
ASTM B575
Plate
Hastelloy C276 Nickel N10276 Plate Hastelloy C276 UNS N10276 B574 Nickel Chromium Molybdenum 3
ASTM B575
Strip
Hastelloy C276 Nickel N10276 Strip Hastelloy C276 UNS N10276 B574 Nickel Chromium Molybdenum 4
ASTM B575
Sheet
Hastelloy C276 Nickel N10276 Sheet Hastelloy C276 UNS N10276 B574 Nickel Chromium Molybdenum 5
ASTM B619
Welded Pipe
Hastelloy C276 Nickel N10276 Welded Pipe Hastelloy C276 UNS N10276 B574 Nickel Chromium Molybdenum 6
ASTM B622
Seamless Tubing
Hastelloy C276 Nickel N10276 Seamless Tubing Hastelloy C276 UNS N10276 B574 Nickel Chromium Molybdenum 7 Hastelloy C276 UNS N10276 B574 Nickel Chromium Molybdenum 8
ASTM B366
Fittings
Hastelloy C276 Nickel N10276 Fittings Hastelloy C276 UNS N10276 B574 Nickel Chromium Molybdenum 9
ASTM B574
Wire
Hastelloy C276 Nickel N10276 Wire
