FeCrAl High Temperature Resistance 1cr13al4 Heating Round Wire For Temperature Sensors

Product Details

Place of Origin: China

Brand Name: DLX

Model Number: 1Cr13Al4

Payment & Shipping Terms

Minimum Order Quantity: 5

Price: Negotiable

Packaging Details: Spool package with Carton box, Coil package with polybag

Delivery Time: 5-21 days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 300 tons per month

Get Best Price
Contact Now
Specifications
Highlight:

FeCrAl Heating Round Wire

,

1cr13al4 Heating Round Wire

,

Temperature Sensors Heating Round Wire

Material:
Ferrous Chromium Aluminum
Resistivity:
1.25+/-0.05
Tensile Strength:
580-680MPA
Elongtation:
≥12%
Application:
Heating, Resistivity
Condition:
Hard / Soft
Sureface:
Bright, Oxided, Acide
Delivery Time:
7-20 Days
Maximum Temperature:
950℃
Melting Point:
1450℃
Material:
Ferrous Chromium Aluminum
Resistivity:
1.25+/-0.05
Tensile Strength:
580-680MPA
Elongtation:
≥12%
Application:
Heating, Resistivity
Condition:
Hard / Soft
Sureface:
Bright, Oxided, Acide
Delivery Time:
7-20 Days
Maximum Temperature:
950℃
Melting Point:
1450℃
Description
FeCrAl High Temperature Resistance 1cr13al4 Heating Round Wire For Temperature Sensors

FeCrAl High Temperature Resistance 1cr13al4 Heating Round Wire For Temperature Sensors 0


  • FeCrAl Series

1Cr13Al4 alloy is a high resistance electric heating alloy, known for its excellent corrosion resistance and high-temperature strength. It has a high electrical resistivity and a low resistance temperature coefficient. The main components of 1Cr13Al4 include chromium, aluminum, nickel, etc., which endow the alloy with good electrical resistivity, high-temperature oxidation resistance, and corrosion resistance.



The 1Cr13Al4 resistance wire is widely used in temperature sensors. A temperature sensor is a device used to measure environmental temperature, and the 1Cr13Al4 resistance wire is one of the important components of it. Its application typically involves using the 1Cr13Al4 resistance wire as the temperature sensing element of the sensor, utilizing its specific resistance-temperature characteristics to measure environmental temperature.



In temperature sensors, the resistance value of the 1Cr13Al4 resistance wire varies with the change in environmental temperature. This variation is based on the relationship between the material properties of the 1Cr13Al4 resistance wire and temperature. By measuring the resistance value of the 1Cr13Al4 resistance wire, the sensor can accurately determine the temperature of the environment and convert it into a corresponding electrical signal output for use by other devices or systems.



The application of 1Cr13Al4 resistance wire in temperature sensors has many advantages. Firstly, it has good stability and repeatability, providing accurate measurements over a wide range of temperatures. Secondly, due to its material properties and cost-effectiveness, 1Cr13Al4 resistance wire is an economically practical choice suitable for various temperature measurement applications. Additionally, it has high corrosion resistance and heat resistance, making it suitable for use in harsh environmental conditions.



Overall, the application of 1Cr13Al4 resistance wire in temperature sensors can provide reliable and accurate temperature measurements, suitable for various industrial, scientific, and household applications.



FeCrAl High Temperature Resistance 1cr13al4 Heating Round Wire For Temperature Sensors 1FeCrAl High Temperature Resistance 1cr13al4 Heating Round Wire For Temperature Sensors 2
















































  • Ferrous Chromium Aluminum alloy performance tables
Alloy Nomenclature Performance 1Cr13Al4 0Cr25Al5 0Cr21Al6 0Cr23Al5 0Cr21Al4 0Cr21Al6Nb 0Cr27Al7Mo2
Main Chemical composition Cr 12.0-15.0 23.0-26.0 19.0-22.0 20.5-23.5 18.0-21.0 21.0-23.0 26.5-27.8
Al 4.0-6.0 4.5-6.5 5.0-7.0 4.2-5.3 3.0-4.2 5.0-7.0 6.0-7.0
Re opportune opportune opportune opportune opportune opportune opportune
Fe Rest Rest Rest Rest Rest Rest Rest
            Nb0.5 Mo1.8-2.2
Max. continuous service temp. of element(°C) 950 1250 1250 1250 1100 1350 1400
Resistivity at 20ºC(μΩ·m) 1.25 1.42 1.42 1.35 1.23 1.45 1.53
Density(g/cm3) 7.4 7.1 7.16 7.25 7.35 7.1 7.1
Thermal conductivity(KJ/m·h·ºC) 52.7 46.1 63.2 60.2 46.9 46.1
Coefficient of lines expansion(α×10-6/ºC) 15.4 16 14.7 15 13.5 16 16
Melting point approx.( ºC) 1450 1500 1500 1500 1500 1510 1520
Tensile strength(N/mm2) 580-680 630-780 630-780 630-780 600-700 650-800 680-830
Elongation at rupture(%) >16 >12 >12 >12 >12 >12 >10
Variation of area(%) 65-75 60-75 65-75 65-75 65-75 65-75 65-75
Repeat Bending frequency(F/R) >5 >5 >5 >5 >5 >5 >5
Hardness(H.B.) 200-260 200-260 200-260 200-260 200-260 200-260 200-260
Continuous Servicetime(Hours/ ºC) -- ≥80/1300 ≥80/1300 ≥80/1300 ≥80/1250 ≥50/1350 ≥50/1350
Micrographic structure Ferrite Ferrite Ferrite Ferrite Ferrite Ferrite Ferrite
Magnetic properties Magnetic Magnetic Magnetic Magnetic Magnetic Magnetic

Magnetic


  • The Form we could offer
Size Range

Wire
dia 0.03-7.5mm
FeCrAl High Temperature Resistance 1cr13al4 Heating Round Wire For Temperature Sensors 3
dia 8.0-12.0mm
FeCrAl High Temperature Resistance 1cr13al4 Heating Round Wire For Temperature Sensors 4
Ribbon
(0.05-0.35)*(0.5-6.0)mm
FeCrAl High Temperature Resistance 1cr13al4 Heating Round Wire For Temperature Sensors 5
Strip
(0.50-2.5)*(5-180)mm
FeCrAl High Temperature Resistance 1cr13al4 Heating Round Wire For Temperature Sensors 6
Rod
8-50mm

FeCrAl High Temperature Resistance 1cr13al4 Heating Round Wire For Temperature Sensors 7
