0.16mm 0.75mm 2mm FeCrAl Alloy 0Cr23Al5 Heating Resistance Wire For Scientific Research

Name: 0.16mm 0.75mm 2mm FeCrAl Alloy 0Cr23Al5 Heating Resistance Wire For Scientific Research
Brand: Changzhou DLX Alloy Co., Ltd.
SKU: 0Cr23Al5
Price: 6.00 USD
Availability: InStock

Brand Name:	DLX
Model Number:	0Cr23Al5
MOQ:	5
Price:	Negotiable
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China Jiangsu

Certification:

CE,ROHS

Material:

Ferrous Chromium Aluminum

Resistivity:

1.35+/-0.05

Tensile Strength:

630-780MPA

Elongtation:

≥12%

Application:

Heating, Resistivity

Condition:

Hard / Soft

Sureface:

Bright, Oxided, Acide

Delivery Time:

7-20 Days

Maximum Temperature:

1250℃

Melting Point:

1500℃

Name:

FeCrAl Resistance Heating Wire

Packaging Details:

Spool package with Carton box, Coil package with polybag

Supply Ability:

500 tons per month

Highlight:

0.75mm FeCrAl Alloy Heating Resistance Wire

0.16mm FeCrAl Alloy Heating Resistance Wire

2mm FeCrAl Alloy Heating Resistance Wire

Product Description

0.16mm 0.75mm 2mm FeCrAl Alloy 0Cr23Al5 Heating Resistance Wire For Scientific Research 0

FeCrAl Series

0Cr23Al5 is a high-performance electric heating alloy widely used in various electric heating equipment and heating elements due to its excellent high-temperature resistance, good oxidation resistance, and excellent mechanical strength.

Heating Element

0Cr23Al5 resistance wire can be used as heating elements in laboratories to heat reagents, samples, or equipment. Its stable resistance characteristics and high temperature performance make it an ideal choice for laboratory heating devices.

Temperature Measurement

Due to the resistance of 0Cr23Al5 resistance wire changing with temperature, they are often used as components in temperature sensors. In scientific research, they can be used to measure the temperature of laboratory equipment, samples, or environments.

Study of Resistance Properties

Due to its temperature-dependent resistance characteristics, 0Cr23Al5 resistance wire is also used to study the resistance properties of materials, including resistivity and temperature dependence.

Chemical Reactions

In certain experiments, where heating or control of chemical reaction processes is required, 0Cr23Al5 resistance wire can provide the necessary heating and control for synthesis or decomposition reactions in the laboratory.

Electrical Testing

In electrical experiments, 0Cr23Al5 resistance wire can be used as components in a resistor box or other circuits for testing and measuring the performance and characteristics of the circuit.

0.16mm 0.75mm 2mm FeCrAl Alloy 0Cr23Al5 Heating Resistance Wire For Scientific Research 1

Ferrous Chromium Aluminum alloy performance tables

Alloy Nomenclature Performance		1Cr13Al4	0Cr25Al5	0Cr21Al6	0Cr23Al5	0Cr21Al4	0Cr21Al6Nb	0Cr27Al7Mo2
Main Chemical composition	Cr	12.0-15.0	23.0-26.0	19.0-22.0	20.5-23.5	18.0-21.0	21.0-23.0	26.5-27.8
	Al	4.0-6.0	4.5-6.5	5.0-7.0	4.2-5.3	3.0-4.2	5.0-7.0	6.0-7.0
	Re	opportune	opportune	opportune	opportune	opportune	opportune	opportune
	Fe	Rest	Rest	Rest	Rest	Rest	Rest	Rest
							Nb0.5	Mo1.8-2.2
Max. continuous service temp. of element(°C)		950	1250	1250	1250	1100	1350	1400
Resistivity at 20ºC(μΩ·m)		1.25	1.42	1.42	1.35	1.23	1.45	1.53
Density(g/cm3)		7.4	7.1	7.16	7.25	7.35	7.1	7.1
Thermal conductivity(KJ/m·h·ºC)		52.7	46.1	63.2	60.2	46.9	46.1
Coefficient of lines expansion(α×10-6/ºC)		15.4	16	14.7	15	13.5	16	16
Melting point approx.( ºC)		1450	1500	1500	1500	1500	1510	1520
Tensile strength(N/mm2)		580-680	630-780	630-780	630-780	600-700	650-800	680-830
Elongation at rupture(%)		>16	>12	>12	>12	>12	>12	>10
Variation of area(%)		65-75	60-75	65-75	65-75	65-75	65-75	65-75
Repeat Bending frequency(F/R)		>5	>5	>5	>5	>5	>5	>5
Hardness(H.B.)		200-260	200-260	200-260	200-260	200-260	200-260	200-260
Continuous Servicetime(Hours/ ºC)		--	≥80/1300	≥80/1300	≥80/1300	≥80/1250	≥50/1350	≥50/1350
Micrographic structure		Ferrite	Ferrite	Ferrite	Ferrite	Ferrite	Ferrite	Ferrite
Magnetic properties		Magnetic	Magnetic	Magnetic	Magnetic	Magnetic	Magnetic	Magnetic

The Form we could offer

Size Range
Wire	dia 0.03-7.5mm
	dia 8.0-12.0mm
Ribbon	(0.05-0.35)*(0.5-6.0)mm

Strip	(0.50-2.5)*(5-180)mm

Rod	8-50mm
