products details

Home Products

Iron Chromium Aluminium Alloy Electrical Heating Alloys 0Cr21Al6Nb Wire For Automotive Industry

Name: Iron Chromium Aluminium Alloy Electrical Heating Alloys 0Cr21Al6Nb Wire For Automotive Industry
Brand: Changzhou DLX Alloy Co., Ltd.
SKU: 0Cr21Al6Nb
Price: 6.00 USD
Availability: InStock

Brand Name:	DLX
Model Number:	0Cr21Al6Nb
MOQ:	5
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China Jiangsu

Certification:

CE,ROHS

Material:

Ferrous Chromium Aluminum

Resistivity:

1.45+/-0.05

Tensile Strength:

630-780MPA

Elongtation:

≥12%

Application:

Heating, Resistivity

Condition:

Hard / Soft

Sureface:

Bright, Oxided, Acide

Delivery Time:

7-20 Days

Maximum Temperature:

1350℃

Melting Point:

1510℃

Name:

Resistance Heating Wire

Packaging Details:

Spool package with Carton box, Coil package with polybag

Supply Ability:

500 tons per month

Highlight:

Electrical Heating Alloys 0Cr21Al6Nb Wire

Automotive Industry 0Cr21Al6Nb Wire

Iron Chromium Aluminium Alloy 0Cr21Al6Nb Wire

Product Description

Iron Chromium Aluminium Alloy Electrical Heating Alloys 0Cr21Al6Nb Wire For Automotive Industry 0

FeCrAl Series

0Cr21Al6Nb alloy has the characteristic of high resistivity, low temperature resistance coefficient, high operating temperature, good anti-oxidation and anti-corrosion under high temperature.

The application of 0Cr21Al6Nb resistance wire in the automotive industry allows vehicles to adapt to various climate conditions and provides a more comfortable and convenient driving experience.

Automotive heating systems

0Cr21Al6Nb resistance wire is widely used in automotive heating systems, such as interior heating systems and seat heaters. They serve as heating elements to provide a comfortable driving environment, especially in cold climate conditions.

Wiper systems

Some automotive wiper systems utilize 0Cr21Al6Nb resistance wire as heating elements to prevent wiper blades from icing up or reduce the workload of the wipers. This helps improve the efficiency and lifespan of the wipers.

Engine preheating systems

In cold regions, diesel vehicles often require preheating the engine to ensure smooth starting. 0Cr21Al6Nb resistance wire can be used in heaters within engine preheating systems to provide sufficient heat to warm up the engine, reducing wear and emissions during startup.

Air conditioning systems

In some high-end automotive air conditioning systems, 0Cr21Al6Nb resistance wire can be used to heat air or liquid for faster warm air or warm water supply. This can enhance passenger comfort and experience.

Iron Chromium Aluminium Alloy Electrical Heating Alloys 0Cr21Al6Nb Wire For Automotive Industry 1

Ferrous Chromium Aluminum alloy performance tables

Alloy Nomenclature Performance		1Cr13Al4	0Cr25Al5	0Cr21Al6	0Cr23Al5	0Cr21Al4	0Cr21Al6Nb	0Cr27Al7Mo2
Main Chemical composition	Cr	12.0-15.0	23.0-26.0	19.0-22.0	20.5-23.5	18.0-21.0	21.0-23.0	26.5-27.8
	Al	4.0-6.0	4.5-6.5	5.0-7.0	4.2-5.3	3.0-4.2	5.0-7.0	6.0-7.0
	Re	opportune	opportune	opportune	opportune	opportune	opportune	opportune
	Fe	Rest	Rest	Rest	Rest	Rest	Rest	Rest
							Nb0.5	Mo1.8-2.2
Max. continuous service temp. of element(°C)		950	1250	1250	1250	1100	1350	1400
Resistivity at 20ºC(μΩ·m)		1.25	1.42	1.42	1.35	1.23	1.45	1.53
Density(g/cm3)		7.4	7.1	7.16	7.25	7.35	7.1	7.1
Thermal conductivity(KJ/m·h·ºC)		52.7	46.1	63.2	60.2	46.9	46.1
Coefficient of lines expansion(α×10-6/ºC)		15.4	16	14.7	15	13.5	16	16
Melting point approx.( ºC)		1450	1500	1500	1500	1500	1510	1520
Tensile strength(N/mm2)		580-680	630-780	630-780	630-780	600-700	650-800	680-830
Elongation at rupture(%)		>16	>12	>12	>12	>12	>12	>10
Variation of area(%)		65-75	60-75	65-75	65-75	65-75	65-75	65-75
Repeat Bending frequency(F/R)		>5	>5	>5	>5	>5	>5	>5
Hardness(H.B.)		200-260	200-260	200-260	200-260	200-260	200-260	200-260
Continuous Servicetime(Hours/ ºC)		--	≥80/1300	≥80/1300	≥80/1300	≥80/1250	≥50/1350	≥50/1350
Micrographic structure		Ferrite	Ferrite	Ferrite	Ferrite	Ferrite	Ferrite	Ferrite
Magnetic properties		Magnetic	Magnetic	Magnetic	Magnetic	Magnetic	Magnetic	Magnetic

The Form we could offer

Size Range
Wire	dia 0.03-7.5mm
	dia 8.0-12.0mm
Ribbon	(0.05-0.35)*(0.5-6.0)mm

Strip	(0.50-2.5)*(5-180)mm

Rod	8-50mm
