FECRAL Alloy 0Cr25Al5 Electric Heating Resistance Flat Wire Woven Wire Mesh For Industrial

Product Details

Place of Origin: China

Brand Name: DLX

Certification: CE,ROHS

Model Number: 0Cr25Al5

Payment & Shipping Terms

Minimum Order Quantity: 2kg

Packaging Details: Spool package with Carton box, Coil package with polybag for pure nickel wire 0.025mm

Delivery Time: 5-21 days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 300 tons per month

Get Best Price
Contact Now
Specifications
Highlight:

China supplier woven wire mesh

,

China supplier Electric Heating Wire Mesh

,

Industrial Electric Heating Wire Mesh

Application:
Heating,Industry,furnace Heating Wire,heater
Shape:
Strip,wire,ribbon,plate,Wire Strip Round Ribbon
Material:
FeCrAl Alloy
Chemical Composition:
Fe Cr Al,Ferro Chrome Aluminium,Cr,Ni,Iron-chromium-aluminum
Dimensions:
Specifications,0.05-12mm,0.01mm-10mm,0.5mm,Ocr25al5 Resistance Strip
Surface:
Bright,bright & Smooth,Bright And Smooth,Polished,acid White/oxidized
Corrosion Resistance:
Excellent
Density:
7.2 G/cm³
Elongation:
≥25%
Formability:
Good
Heat Treatment:
Annealing
Machinability:
Good
Magnetic Properties:
Ferromagnetic
Melting Point:
1400-1450°C
Oxidation Resistance:
Excellent
Tensile Strength:
≥400 MPa
Thermal Conductivity:
14-20 W/mK
Thermal Expansion:
8.2-9.2 μm/mK
Weldability:
Good
Yield Strength:
≥200 MPa
Application:
Heating,Industry,furnace Heating Wire,heater
Shape:
Strip,wire,ribbon,plate,Wire Strip Round Ribbon
Material:
FeCrAl Alloy
Chemical Composition:
Fe Cr Al,Ferro Chrome Aluminium,Cr,Ni,Iron-chromium-aluminum
Dimensions:
Specifications,0.05-12mm,0.01mm-10mm,0.5mm,Ocr25al5 Resistance Strip
Surface:
Bright,bright & Smooth,Bright And Smooth,Polished,acid White/oxidized
Corrosion Resistance:
Excellent
Density:
7.2 G/cm³
Elongation:
≥25%
Formability:
Good
Heat Treatment:
Annealing
Machinability:
Good
Magnetic Properties:
Ferromagnetic
Melting Point:
1400-1450°C
Oxidation Resistance:
Excellent
Tensile Strength:
≥400 MPa
Thermal Conductivity:
14-20 W/mK
Thermal Expansion:
8.2-9.2 μm/mK
Weldability:
Good
Yield Strength:
≥200 MPa
Description
FECRAL Alloy 0Cr25Al5 Electric Heating Resistance Flat Wire Woven Wire Mesh For Industrial

FECRAL Alloy 0Cr25Al5 Electric Heating Resistance Flat Wire Woven Wire Mesh For Industrial 0FECRAL Alloy 0Cr25Al5 Electric Heating Resistance Flat Wire Woven Wire Mesh For Industrial 1

China supplier FECRAL alloy 0Cr25Al5 electric heating resistance flat wire

OCr25Al5 Electric Resistance Heating Wire is one kind of normal material of Fe-Cr-Al alloy.

FeCrAl alloy has the characteristic of high resistivity,low temperature resistance coefficient,high operating temperature,good anti-oxidation and anti-corrosion under high temperature.

It is widely used in industrial furnace, household appliances, industry furnace, metallurgy, machinery, aircraft, automotive, military and other industries producing heating elements and resistance elements.



Size dimension range:

Wire: 0.01-10mm

Ribbons: 0.05*0.2-2.0*6.0mm

Strip: 0.05*5.0-5.0*250mm

Bar:10-50mm

FeCrAl alloy series: OCr15Al5,1Cr13Al4, 0Cr21Al4, 0Cr21Al6, 0Cr23Al5, 0Cr25Al5, 0Cr21Al6Nb,0Cr27Al7Mo2, and etc.



Alloy Nomenclature Performance
1Cr13AL4
0Cr25Al5
0Cr21AL6
0Cr23Al5
0Cr21Al4
0Cr21Al6Nb
0Cr27Al7Mo2


Main Chemical composition
Cr
12.0-15.0
23.0-26.0
19.0-22.0
20.5-23.5
18.0-21.0
21.0-23.0
26.5-27.8
Al
4.0-6.0
4.5-6.5
5.0-7.0
4.2-5.3
3.0-4.2
5.0-7.0
6.0-7.0
Re
opportune
opportune
opportune
opportune
opportune
opportune
opportune
Fe
Rest
Rest
Rest
Rest
Rest
Rest
Rest






Nb0.5
Mo1.8-2.2
Max. continuous service temp. of element(°C)
950
1250
1250
1250
1100
1350
1400
Resistivity at 20ºC(μΩ·m)
1.25
1.42
1.42
1.35
1.23
1.45
1.53
Density(g/cm3)
7.4
7.1
7.16
7.25
7.35
7.1
7.1
Thermal conductivity(KJ/m·h·ºC)
52.7
46.1
63.2
60.2
46.9
46.1
--
Coefficient of lines expansion(α×10-6/ºC)
15.4
16
14.7
15
13.5
16
16
Melting point approx.( ºC)
1450
1500
1500
1500
1500
1510
1520
Tensile strength(N/mm2)
580-680
630-780
630-780
630-780
600-700
650-800
680-830
Elongation at rupture(%)
>16
>12
>12
>12
>12
>12
>10
Variation of area(%)
65-75
60-75
65-75
65-75
65-75
65-75
65-75
Repeat Bending frequency(F/R)
>5
>5
>5
>5
>5
>5
>5
Hardness(H.B.)
200-260
200-260
200-260
200-260
200-260
200-260
200-260
continuous service time(Hours/ ºC)
--
≥80/1300
≥80/1300
≥80/1300
≥80/1250
≥50/1350
≥50/1350
Micrographic structure
Ferrite
Ferrite
Ferrite
Ferrite
Ferrite
Ferrite
Ferrite
Magnetic properties
Magnetic
Magnetic
Magnetic
Magnetic
Magnetic
Magnetic
Magnetic



FECRAL Alloy 0Cr25Al5 Electric Heating Resistance Flat Wire Woven Wire Mesh For Industrial 2FECRAL Alloy 0Cr25Al5 Electric Heating Resistance Flat Wire Woven Wire Mesh For Industrial 3FECRAL Alloy 0Cr25Al5 Electric Heating Resistance Flat Wire Woven Wire Mesh For Industrial 4
