Weldability Solderability Monel 400 Wires For Cryogenic Fluid Handling

Place of Origin China
Brand Name DLX
Model Number Monel 400
Minimum Order Quantity 5
Price $30-$50
Packaging Details Spool package with Carton box, Coil package with polybag for monel 400 wire
Payment Terms L/C, T/T, Western Union, MoneyGram
Supply Ability 300 tons per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

WeChat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Delivery Time 7-50 Days Material Nickel Copper
Nickel(Min) 63% Curie Temperature 21-49℃
Density 8.05g/cm3 Application Anti-corrosion
Condition Hard / Soft Sureface Bright,Oxided
Melting Point 1288-1343℃ Name Monel 400 Wire

Anti Corrosion Monel 400 Wires


Cryogenic Fluid Handling Monel Wires


Nickel Copper Monel 400 Wires

Leave a Message
Product Description

Weldability Solderability Monel 400 Wires For Cryogenic Fluid Handling 0

Weldability Solderability Monel 400 Wires For Cryogenic Fluid Handling

  • Monel Series

Monel 400 is a high-strength single-phase solid solution, which is the largest and most widely used corrosion-resistant alloy with excellent comprehensive properties. The alloy is exposed to hydrofluoric acid and fluorine gas media. It has excellent corrosion resistance and also has excellent corrosion resistance to hot concentrated alkaline solution.


  • Chemical Properties of Monel 400

Ni Cu Al Ti C Mn Fe S Si
63.0-70.0 27-33 2.30-3.15 0.35-0.85 0.25 max 1.5 max 2.0 max 0.01 max 0.50 max


  • Production Process:

1. Raw Material Selection: The first step in producing Monel 400 wire is selecting high-quality nickel and copper as raw materials. These raw materials must meet stringent quality standards to ensure the final product has excellent performance.

2. Alloy Melting: The selected nickel and copper raw materials are mixed in specific proportions and melted at high temperatures to produce Monel 400 alloy. During the melting process, temperature and composition must be strictly controlled to ensure the quality and stability of the alloy.

3. Billet Preparation: The melted Monel 400 alloy is cast into appropriate-sized billets, typically round or square in shape.

4. Billet Heat Treatment: The billets undergo heat treatment to relieve internal stresses and improve the material's mechanical properties. This step is crucial to ensuring the quality of the final wire.

5. Drawing Process: The heat-treated billets are fed into drawing machines, where they are gradually reduced in diameter through continuous drawing to produce Monel 400 wire of the desired diameter and gauge.

6. Surface Treatment: The Monel 400 wire, after drawing, undergoes surface treatments such as pickling, polishing, etc., to improve surface quality and smoothness.

7. Testing and Packaging: The produced Monel 400 wire undergoes rigorous quality testing to ensure it meets customer requirements and standards. It is then packaged and labeled for shipment to customers.


Weldability Solderability Monel 400 Wires For Cryogenic Fluid Handling 1

  • Mechanical Properties

Product Form Condition Tensile (ksi) .2% Yield (ksi) Elongation % Hardness
Rod & Bar Hot-Finished/Aged 140-190 100-150 30-20 27-38 HRC
Rod & Bar Hot Finished/Annealed 90-110 40-60 45-25 75-90 HRB
Rod & Bar Hot Finished/Annealed/Aged 130-165 85-120 35-20 24-35 HRC
Rod & Bar Cold-Drawn/Aged 135-185 95-160 30-15 25-41 HRC
Rod & Bar Cold-Drawn/Annealed/Aged 130-190 85-120 30-20 24-35 HRC
Plate ot-Finished/Aged 140-180 100-135 30-20 27-37 HRC
Sheet Cold-Rolled/Annealed 90-105 40-65 45-25 85 HRB Max


  • Application

1. Marine Engineering: Monel 400 wire is commonly used in the manufacturing of marine engineering equipment such as seawater desalination units, seawater pumps, and offshore oil pipelines, highly favored for its resistance to seawater corrosion.

2. Chemical Industry: Due to its corrosion resistance to various chemicals, Monel 400 wire is widely employed in the chemical industry for manufacturing chemical reactors, piping for acidic environments, and chemical equipment.

3. Aerospace Industry: Monel 400 wire is also utilized in the aerospace sector for fabricating components of aircraft and spacecraft, including engine parts, structural brackets, and hydraulic systems.

4. Marine Vessels: In the marine vessel sector, Monel 400 wire finds extensive use in the manufacturing of ship equipment and components such as hull structures, marine valves, and pipe fittings, to withstand corrosion from seawater and the marine environment.

5. Chemical Processing: Monel 400 wire is also commonly used in chemical processing and fine chemical industries for manufacturing corrosion-resistant equipment and piping systems, including chlorine processing units and petroleum processing equipment.

Weldability Solderability Monel 400 Wires For Cryogenic Fluid Handling 2

Weldability Solderability Monel 400 Wires For Cryogenic Fluid Handling 3Weldability Solderability Monel 400 Wires For Cryogenic Fluid Handling 4
