ASTM ASME Monel K500 Bar K500 Nickel Copper Alloy Customized

ASTM ASME Monel K500 Bar K500 Nickel Copper Alloy Customized

Brand Name:	DLX
Model Number:	Monel 400 rod
MOQ:	5
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China Jiangsu

Certification:

CE,ROHS

Material:

Nickel Copper

Nickel(Min):

63%

Curie Temperature:

21-49℃

Density:

8.05g/cm3

Application:

Anti-corrosion

Condition:

Hard / Soft

Sureface:

Bright,Oxided

Delivery Time:

7-50 Days

Melting Point:

1288-1343℃

Name:

Monel K500 Tube

Packaging Details:

Spool package with Carton box, Coil package with polybag

Supply Ability:

500 tons per month

Highlight:

Customized Monel K500 Bar

K500 Nickel Copper Alloy

Monel K500 Welding Bar

Product Description

Monel K500 Bar - K500 Nickel Copper Alloy

Monel k500 rod is a nickel copper alloy pipe with excellent corrosion resistance, particularly suitable for seawater and saline environments. It also has good mechanical properties and high-temperature resistance, so it is commonly used in fields such as chemical engineering, ocean engineering, shipbuilding, etc.

Name		Monel 400(N04400)	Monel K500(N05500)
Chemmical Composition wt.%	Ni	63.0-67.0	63.0-67.0
	Fe	≤2.00	≤2.00
	C	≤0.03	≤0.25
	Mn	≤1.50	≤0.15
	P	-	-
	Si	≤0.50	≤1.00
	Cu	28.0-34.0	margin
	S	-	≤0.01
	Cr	-	-
	Al	-	2.0-4.0
	TI	-	0.25-1.00
	Others	-	-

Product name	High Strength NO4400 Nickel Alloy Rod Monel 400 Nickel Bar
Standard	ASTM,ASME
Diameter	3-480mm or customized
Length	3000mm,4000mm,5800mm,6000mm,12000mm, or as required
Density	8.9cm3
Nickel Content	58%
Lead Time	7-15 working days after the receipt of 30% deposit
Payment Terms	30% TT for deposit,70% TT/LC at sight balance before shipment
Price terms	FOB EXW CIF CFR
Packing	Wooden Pallet or according to customer's requirements

ASTM ASME Monel K500 Bar K500 Nickel Copper Alloy Customized 0

Application

. Sour-gas service applications
. Oil and gas production safety lifts and valves
. Oil-well tools and instruments like drill collars
. Oil well industry
. Doctor blades and scrapers
. Chains, cables, springs, valve trim, fasteners for marine service
. Pump shafts and impellers in marine service

ASTM ASME Monel K500 Bar K500 Nickel Copper Alloy Customized 2

Mechanical Properties

Typical Room Temperature Tensile Properties of Annealed Material

Product Form	Condition	Tensile (ksi)	.2% Yield (ksi)	Elongation %	Hardness
Rod & Bar	Hot-Finished/Aged	140-190	100-150	30-20	27-38 HRC
Rod & Bar	Hot Finished/Annealed	90-110	40-60	45-25	75-90 HRB
Rod & Bar	Hot Finished/Annealed/Aged	130-165	85-120	35-20	24-35 HRC
Rod & Bar	Cold-Drawn/Aged	135-185	95-160	30-15	25-41 HRC
Rod & Bar	Cold-Drawn/Annealed/Aged	130-190	85-120	30-20	24-35 HRC
Plate	ot-Finished/Aged	140-180	100-135	30-20	27-37 HRC
Sheet	Cold-Rolled/Annealed	90-105	40-65	45-25	85 HRB Max

ASTM ASME Monel K500 Bar K500 Nickel Copper Alloy Customized 3

contact us:

email:sales7@dlx-alloy.com

Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
Product Available Size:
Wires: Diameter0.5~7.5mm

Rods:Diameter8.0~200mm
Strip:Thickness0.5~2.5mm, Width5~180mm
Plate: Customized
Tube: Customized

After sale service:
24 hours on for after sale service
