Monel K500 Tube Corrosion Resistant Alloys Nickel Alloy Pipe

Product Details

Place of Origin: China

Brand Name: DLX

Certification: CE,ROHS

Model Number: Monel K500

Payment & Shipping Terms

Minimum Order Quantity: 5

Packaging Details: Spool package with Carton box, Coil package with polybag

Delivery Time: 5-21 days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 300 tons per month

Get Best Price
Contact Now
Specifications
Highlight:

Monel K500 Tube

,

Corrosion Resistant Monel K500 Tube

,

Monel K500 Pipe

Material:
Nickel Copper
Nickel(Min):
63%
Curie Temperature:
21-49℃
Density:
8.05g/cm3
Application:
Anti-corrosion
Condition:
Hard / Soft
Sureface:
Bright,Oxided
Delivery Time:
7-50 Days
Melting Point:
1288-1343℃
Name:
Monel K500 Tube
Material:
Nickel Copper
Nickel(Min):
63%
Curie Temperature:
21-49℃
Density:
8.05g/cm3
Application:
Anti-corrosion
Condition:
Hard / Soft
Sureface:
Bright,Oxided
Delivery Time:
7-50 Days
Melting Point:
1288-1343℃
Name:
Monel K500 Tube
Description
Monel K500 Tube Corrosion Resistant Alloys Nickel Alloy Pipe

Monel K500 Tube Corrosion Resistant Alloys Nickel Alloy Pipe 0

Monel K500 tube Corrosion Resistant Alloys nickel alloy pipe

What material is monelk500?

   Monel K500 is a high-strength, corrosion-resistant nickel copper alloy material. It is composed of about 65% nickel and about 30% copper, while containing small amounts of elements such as aluminum, iron, carbon, manganese, and titanium. The Monel K500 has excellent corrosion resistance, especially in corrosive media such as seawater, sulfuric acid, and hydrochloric acid. In addition, the Monel K500 also has good wear resistance, high temperature resistance, and fatigue resistance, making it widely used in marine engineering, chemical equipment, aerospace and other fields.

Monel K500 Tube Corrosion Resistant Alloys Nickel Alloy Pipe 1Monel K500 Tube Corrosion Resistant Alloys Nickel Alloy Pipe 2




  • Chemical Properties of Monel K500

Ni Cu Al Ti C Mn Fe S Si

63

Max

27-33 2.3-3.15 0.35-0.85 0.25 max 1.5 max 2.0 max 0.01 max 0.50 max


  • Application

. Sour-gas service applications
. Oil and gas production safety lifts and valves
. Oil-well tools and instruments like drill collars
. Oil well industry
. Doctor blades and scrapers
. Chains, cables, springs, valve trim, fasteners for marine service
. Pump shafts and impellers in marine service

Monel K500 Tube Corrosion Resistant Alloys Nickel Alloy Pipe 3

Mechanical Properties

Typical Room Temperature Tensile Properties of Annealed Material

Product Form Condition Tensile (ksi) .2% Yield (ksi) Elongation % Hardness
Rod & Bar Hot-Finished/Aged 140-190 100-150 30-20 27-38 HRC
Rod & Bar Hot Finished/Annealed 90-110 40-60 45-25 75-90 HRB
Rod & Bar Hot Finished/Annealed/Aged 130-165 85-120 35-20 24-35 HRC
Rod & Bar Cold-Drawn/Aged 135-185 95-160 30-15 25-41 HRC
Rod & Bar Cold-Drawn/Annealed/Aged 130-190 85-120 30-20 24-35 HRC
Plate ot-Finished/Aged 140-180 100-135 30-20 27-37 HRC
Sheet Cold-Rolled/Annealed 90-105 40-65 45-25 85 HRB Max

Monel K500 Tube Corrosion Resistant Alloys Nickel Alloy Pipe 4Monel K500 Tube Corrosion Resistant Alloys Nickel Alloy Pipe 5

contact us:

email:sales7@dlx-alloy.com

Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
Product Available Size:
Wires: Diameter0.5~7.5mm

Rods:Diameter8.0~200mm
Strip:Thickness0.5~2.5mm, Width5~180mm
Plate: Customized
Tube: Customized
