Bright Inconel 625 Tube With Ni Co Mn Material

Product Details

Place of Origin: China

Brand Name: DLX

Certification: CE,ROHS

Model Number: inconel 600 tube

Payment & Shipping Terms

Minimum Order Quantity: 5

Price: $30-$50

Packaging Details: Inconel 625 bar packed in wooden case

Delivery Time: 5-21 days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 300 tons per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                  Bright Inconel 625 Tube, 58% Ni Inconel 625 Tube, Inconel 625 Seamless Tubes


Material:	Ni Co Mn	Nickel(Min):	58%
Thermal Conductivity:	9.8 W/m*℃	Curie Point:	-319℉ (-195℃)
Density:	8.44 G/cm3	Yield Strength:	479.2-528.8 MPA
Condition:	Hard / Soft	Sureface:	Bright,Oxided
Delivery Time:	7-50 Days	Tensile Strength:	1276-1034 MPA
Melting Point:	1350℃	Elongation:	34-54%
Product Name:	Competitive Price Nickel-based Alloy Inconel 625 Bar

Material:	Ni Co Mn
Nickel(Min):	58%
Thermal Conductivity:	9.8 W/m*℃
Curie Point:	-319℉ (-195℃)
Density:	8.44 G/cm3
Yield Strength:	479.2-528.8 MPA
Condition:	Hard / Soft
Sureface:	Bright,Oxided
Delivery Time:	7-50 Days
Tensile Strength:	1276-1034 MPA
Melting Point:	1350℃
Elongation:	34-54%
Product Name:	Competitive Price Nickel-based Alloy Inconel 625 Bar

Description

Bright Inconel 625 Tube With Ni Co Mn Material

Inconel 625 Tube

Bright Inconel 625 Tube With Ni Co Mn Material 0 Inconel Series

• We can supply all kinds of bar, forging, ring, hot rolled plate, cold rolled plate, strip, pipe and wire.

Plate and strip are generally supplied after hot or cold rolling, annealing or solid solution, pickling and polishing.
• Rods, forgings and rings may be supplied in the form of forging or hot rolling;It can also be supplied with solid solution after forging.The bar can be polished or polished after solid solution.When the order is required, it can be placed in the cold drawing state.
• Silk can be supplied in solid solution state.For silk materials with nominal diameter or thickness less than 6.35mm, it can be provided with 50% ~ 65% cold drawing deformation after solid dissolution.Silk material with nominal diameter or side length greater than 6.35mm shall be supplied with no less than 30% cold drawing deformation after solid solution treatment.For silk materials with nominal diameter or side length not exceeding 0.65mm, according to the requirements of solid solution treatment, no less than 15% cold drawing deformation is provided.

Chemical Properties Of Inconel 625 tube

Steel grade	Inconel 600	Inconel 601	Inconel 625	Inconel 718	Inconel 725	Inconel X-750
Corresponding brand	N06600/2.4816/1Cr15Ni75Fe8/NS312/CY40	N06601/2.4851/1Cr23Ni60Fe13AI/NS313	N06625/2.4856/0Cr20Ni65Mo10bN4/NS336	N07718/2.4668/GH4169	N07725	N07750/2.4669/GH4145
Chemical composition%
C≤	0.150	0.100	0.100	0.080	0.030	0.080
Mn≤	1.00	1.00	0.50	0.35	0.35	1.00
P≤	/	/	0.015	0.015	0.015	/
S≤	0.015	0.015	0.015	0.015	0.010	0.010
Si≤	0.50	0.50	0.50	0.35	0.20	0.50
Cr≤	14.0-17.0	21.0-25.0	20.0-23.0	17.0-21.0	19.0-22.5	14.0-17.0
Ni≤	≥72.0	58.0-63.0	≥58.0	55.0-59.0	55.0-59.0	≥70
Mo	/	/	8.0-10.0	2.8-3.3	7.0-9.5	/
Cu	≤0.50	≤1.50	/	≤0.30	/	≤0.50
N	/	/	/		/	/
Nb	/	/	3.15-4.15	4.75-5.50	2.75-4.00	0.70-1.20
other	Fe:6.0-10.0	Al:1.0-1.7	Co:≤1.0Ai:≤0.40Tr:0.40Fe:≤5.0	AI:0.20-0.80Ti:0.65-1.15B≤0.006	Tr:1.0-1.7AI≤0.35	Co:≤1.0 AI:0.4-1.0Tr:0.25-2.75Fe:5.0-9.0

The applications of Inconel 625 tube include:

Alloy 625 own a very good corrosion resistance in many media, especially with excellent resistance to pitting, crevice corrosion,intercrystalline corrosion, and erode in oxide, also good resistance to inorganic acid corrosion, such as nitric acid, phosphoric acid, sulfuric acid and hydrochloric acid.

Alloy 625 can resist the alkali and organic acid corrosion in the oxidation and reduction environment. Effect resists the chloride reduction stress corrosion cracking. Normally no corrosion in the sea-water and industry environments since high corrosion resistance to the sea-water and salting liquid,as well as in high temperature, without sensitivity during welding.

Alloy 625 have the resistance to oxidation and carbonizing in the static and cycle environments, also hacve the resistance the chlorine corrosion.

Bright Inconel 625 Tube With Ni Co Mn Material 1

contact us:

email:sales7@dlx-alloy.com

Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
Product Available Size:
Wires: Diameter0.5~7.5mm

Rods:Diameter8.0~200mm
Strip:Thickness0.5~2.5mm, Width5~180mm
Plate: Customized
Tube: Customized

After sale service:
24 hours on alibaba for after sale service
Alibaba trade assurance
