1034 MPA High Temperature Nickel Alloy 625 Tubing

Product Details

Place of Origin: China

Brand Name: DLX

Model Number: Inconel 625

Payment & Shipping Terms

Minimum Order Quantity: 5

Price: $30-$50

Packaging Details: High temperature nickel-based alloy 625 nickel tubing packed in wooden case

Delivery Time: 5-21 days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 300 tons per month

Get Best Price
Contact Now
Specifications
Highlight:

1034 MPA Alloy 625 Tubing

,

High Temperature Inconel Steel

,

AMS 5581 Alloy 625 Tubing

Material:
Ni Co Mn
Nickel(Min):
58%
Thermal Conductivity:
9.8 W/m*℃
Curie Point:
-319℉ (-195℃)
Density:
8.44 G/cm3
Yield Strength:
479.2-528.8 MPA
Condition:
Hard / Soft
Sureface:
Bright,Oxided
Delivery Time:
7-50 Days
Tensile Strength:
1276-1034 MPA
Melting Point:
1350℃
Elongation:
34-54%
Product Name:
High Temperature Nickel-based Alloy 625 Nickel Tubing
Material:
Ni Co Mn
Nickel(Min):
58%
Thermal Conductivity:
9.8 W/m*℃
Curie Point:
-319℉ (-195℃)
Density:
8.44 G/cm3
Yield Strength:
479.2-528.8 MPA
Condition:
Hard / Soft
Sureface:
Bright,Oxided
Delivery Time:
7-50 Days
Tensile Strength:
1276-1034 MPA
Melting Point:
1350℃
Elongation:
34-54%
Product Name:
High Temperature Nickel-based Alloy 625 Nickel Tubing
Description
1034 MPA High Temperature Nickel Alloy 625 Tubing

1034 MPA High Temperature Nickel Alloy 625 Tubing 0


1034 MPA High Temperature Nickel Alloy 625 Tubing 1


  • Inconel Series

The alloy 625 nickel tubing is a non-magnetic nickel-chromium superalloy that features superb corrosion resistance as expected by the presence of the aforementioned transition metals. Moreover, it is very strong and is characterized by the wide range of its fabrication possibilities.

The safe operating temperature range of alloy 625 nickel tubing spans from -238℉ (-150℃) to up to 1800℉ (982℃), so it can be used in a wide spectrum of applications that require exceptional corrosion resistance characteristics.

Variable temperatures are not the only thing that the alloy 625 nickel tubing can withstand, as the same applies for variable pressures and very harsh environments that induce high rates of oxidation. In general, it finds application in sea-water applications, the chemical processing industry, the nuclear energy field, and also the aerospace sector.

As it is evident from the latter especially, the alloy 625 nickel tubing is also very resistant to cracking, rupture and creeping damage, featuring high tensile strength and extraordinary corrosion versatility.






  • Chemical Properties Of Alloy 625 Nickel Tubing

Nickel Chromium Molybdenum Iron Niobium and Tantalum Cobalt Manganese Silicon
58% 20%-23% 8%-10% 5% 3.15%-4.15% 1% 0.5% 0.5%



  • Application

Some typical applications are:

  1. The core of mooring cables
  2. Submarine propeller blades
  3. Submarine propulsion unit caging
  4. Navy boat exhaust ducts
  5. Undersea communication cables sheathing
  6. Other submerged systems or instruments
  7. Aircraft ducts and exhausts
  8. Thrust-reversers
  9. Engine compartment housing
  10. Fuel and hydraulics tubing
  11. Turbine seals
  12. Reactor core components
  13. Fuel control rod components
  14. General plant equipment
  15. Vessels
  16. Honeycomb heat exchangers
  17. Various types of industrial tubing
  18. Distillation columns
  19. Valves
  20. Super-heated potassium and sodium solar power stations tubing




  • ,Type we could offer
    AMS Number Alloy Type UNS Cross Ref. Spec Misc./Shape
    AMS 5581 Inconel 625 Nickel N06625
    AMS 5581 Custom Tube Inconel 625 Nickel N06625 - Custom Tube AMS 5581 Custom Tube
    AMS 5581 Tubing Inconel 625 Nickel N06625 - Tubing AMS 5581 Tubing
    AMS 5599 Inconel 625 Nickel N06625
    AMS 5599 Plate Inconel 625 Nickel N06625 - Plate AMS 5599 Plate
    AMS 5599 Sheet Inconel 625 Nickel N06625 - Sheet AMS 5599 Sheet
    AMS 5599 Strip Inconel 625 Nickel N06625 - Strip AMS 5599 Strip
    AMS 5666 Inconel 625 Nickel N06625
    AMS 5666 Bar Inconel 625 Nickel N06625 - Bar AMS 5666 Bar
    AMS 5666 Custom Tube Inconel 625 Nickel N06625 - Custom Tube AMS 5666 Custom Tube
    AMS 5666 Forging Inconel 625 Nickel N06625 - Forging AMS 5666 Forging
    AMS 5666 Ring Inconel 625 Nickel N06625 - Ring AMS 5666 Ring
    AMS 5869 Inconel 625 Nickel N06625
    AMS 5869 Plate Inconel 625 Nickel N06625 - Plate AMS 5869 Plate
    AMS 5869 Sheet Inconel 625 Nickel N06625 - Sheet AMS 5869 Sheet
    AMS 5869 Strip Inconel 625 Nickel N06625 - Strip AMS 5869 Strip
