Product Details
Place of Origin: China Jiangsu
Brand Name: DLX
Certification: CE,ROHS
Model Number: Monel 400 pipe
Payment & Shipping Terms
Minimum Order Quantity: 5
Packaging Details: Spool package with Carton box, Coil package with polybag
Delivery Time: 5-20 Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500 tons per month
Material: |
Monel 400 |
Nickel(Min): |
63% |
Curie Temperature: |
21-49℃ |
Density: |
8.8g/cm3 |
Application: |
Anti-corrosion |
Condition: |
Hard / Soft |
Sureface: |
Bright,Oxided |
Delivery Time: |
7-50 Days |
Melting Point: |
.1300-1350℃ |
Name: |
Monel 400 Tube |
Material: |
Monel 400 |
Nickel(Min): |
63% |
Curie Temperature: |
21-49℃ |
Density: |
8.8g/cm3 |
Application: |
Anti-corrosion |
Condition: |
Hard / Soft |
Sureface: |
Bright,Oxided |
Delivery Time: |
7-50 Days |
Melting Point: |
.1300-1350℃ |
Name: |
Monel 400 Tube |
What material is monel400?
Monel 400 is a nickel copper alloy that contains approximately 67% nickel and 23% copper. It also contains small amounts of elements such as iron, manganese, silicon, and carbon. Monel 400 has excellent corrosion resistance and can be used for pipelines, tanks, valves, and other equipment in highly corrosive media such as seawater, sulfuric acid, and hydrochloric acid. In addition, Monel 400 also has good wear resistance, high strength, and excellent high-temperature resistance, making it widely used in fields such as aerospace, chemical engineering, and ocean engineering.
| C | Mn | S | Si | Ni | Cu | Fe |
|---|---|---|---|---|---|---|
| .30 max | 2.00 max | .024 max | .50 max | 63.0 min | 28.0-34.0 | 2.50 max |
Alloy 400 has been widely used in a variety of industries, and has been particularly useful in the marine industry and chemical processing industry. Typical applications include pumps and valves, propeller shafts, marine fixtures and fasteners, electronic components, springs, chemical processing equipment, fresh and salt water tanks, process vessels and piping, boiler feedwater heaters and other heat exchangers.
| AMS Number | Alloy | Type | UNS | Cross Ref. Spec | Misc./Shape | |
|---|---|---|---|---|---|---|
| AMS 4544 Plate | Monel 400 | Nickel Copper | N04400 | QQ-N-281 | Plate | |
| AMS 4544 Sheet | Monel 400 | Nickel Copper | N04400 | QQ-N-281 | Sheet | |
| AMS 4544 Strip | Monel 400 | Nickel Copper | N04400 | QQ-N-281 | Strip | |
| AMS 4574 | Monel 400 | Nickel Copper | N04400 | - | Tubing | |
| AMS 4675 Bar | Monel 400 | Nickel Copper | N04400 | ASTM B 164 | Bar | |
| AMS 4730 | Monel 400 | Nickel Copper | N04400 | QQ-N-281 | Wire | |
| AMS 4731 Ribbon | Monel 400 | Nickel Copper | N04400 | - | Ribbon | |
| AMS 4731 Wire | Monel 400 | Nickel Copper | N04400 | - | Wire | |
