ASTM Hot Rolled Nickel Alloy Inconel 600 601 625 718 X750 800 Strip

Brand Name:	DLX
Model Number:	Inconel X-750
MOQ:	5
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China Jiangsu

Certification:

CE,ROHS

Material:

Ni Cr Ti

Nickel(Min):

70%

Magnetic Permeability:

1.0035

Curie Temperature:

-125 °C

Density:

8.28 G/cm3

CTE, Linear 20°C:

12.6 µm/m-°C

Condition:

Hard / Soft

Sureface:

Bright,Oxided

Delivery Time:

7-50 Days

Tensile Strength:

760-1600MPA

Melting Point:

1390 - 1430℃

Specific Heat Capacity:

0.431 J/g-°C

Thermal Conductivity:

12 W/m-K

Elongation:

30 %

Name:

Inconel X750 Rod

Packaging Details:

Spool package with Carton box, Coil package with polybag

Supply Ability:

500 tons per month

Highlight:

ASTM Hot Rolled Nickel Alloy

Nickel Alloy Inconel 600

Inconel 800 Strip

Product Description

ASTM hot rolled nickel alloy inconel 600 601 625 718 X750 800 strip

ASTM Hot Rolled Nickel Alloy Inconel 600 601 625 718 X750 800 Strip 0

Inconel Series

Inconel is a family of austenitic nickel-chromium-based super alloys.

Inconel alloys are oxidation-corrosion-resistance materials well suited for service in extreme environments subjected to pressure and heat.When heated,Inconel forms a thick,stable,passivating oxide layer protecting the surface from further attack.Inconel retains strength over a wide temperature range,attractive for high temperature applications where aluminum and steel would succumb to creep as a result of thermally induced crystal vacancies,Inconel's high temperature strength is developed by solid solution strengthening or precipitation hardening,depending on the alloy.

Size dimension range:

Wire: 0.01-10mm

Strip: 0.05*5.0-5.0*250mm

Bar: φ4-50mm;Length 2000-5000mm

Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm

Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm

Inconel series: 600,601,617,625,690,718,X-750,825

Chemical Properties of Inconel X750

Element

Ni +Co

Iron

Chemical Composition (%)

70% Min

14%-

17%

0.7%-

1.2%

2.25%-

2.75%

0.08% max

1% max

0.5% max

0.30% max

0.4%-1.0%

0.01% max

5%-9%

Application

Some typical applications are:

Gas turbines
Jet engine parts
Nuclear power plant applications
Heat-treating fixtures
Forming tools and extrusion dies
Pressure vessels
Aircraft structures

,Type we could offer

AMS Number	Alloy	Type	UNS	Cross Ref. Spec	Misc./Shape
AMS 5699 wire	Inconel X750	Nickel	N07750	Wire
AMS 5542 Custom Tube	Inconel X750	Nickel	N07750	-	Custom Tube
AMS 5542 Plate	Inconel X750	Nickel	N07750	-	Plate
AMS 5542 Sheet	Inconel X750	Nickel	N07750	-	Sheet
AMS 5542 Strip	Inconel X750	Nickel	N07750	-	Strip
