Innovative Heat Treatment Processes For Inconel 718 Tube Production

Product Details

Place of Origin: China

Brand Name: DLX

Model Number: Inconel 718 tube

Payment & Shipping Terms

Minimum Order Quantity: 5

Packaging Details: Inconel 718 wire packed in Spool Carton box, Coil package with polybag,then in woodencase

Delivery Time: 5-21 days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 300 tons per month

Get Best Price
Contact Now
Specifications
Highlight:

Heat Treatment Inconel 718 Tube

,

50%Ni Inconel 718 Tube

,

AMS Inconel Alloy Tube

Material:
Ni Cr Fe
Nickel(Min):
50%
Magnetic Permeability:
1.0011
Curie Temperature:
-112 °C
Density:
8.19
CTE, Linear 20°C:
13 µm/m-°C
Condition:
Hard / Soft
Sureface:
Bright,Oxided
Delivery Time:
7-50 Days
Tensile Strength:
760-1600MPA
Melting Point:
1260 - 1336℃
Specific Heat Capacity:
0.435 J/g-°C
Thermal Conductivity:
11.4 W/m-K
Elongation:
25 %
Product Name:
Nickel-based Alloy AMS 5596 Inconel 718 Nickel Alloy Plate/Nickel Tube For Aeronautical
Material:
Ni Cr Fe
Nickel(Min):
50%
Magnetic Permeability:
1.0011
Curie Temperature:
-112 °C
Density:
8.19
CTE, Linear 20°C:
13 µm/m-°C
Condition:
Hard / Soft
Sureface:
Bright,Oxided
Delivery Time:
7-50 Days
Tensile Strength:
760-1600MPA
Melting Point:
1260 - 1336℃
Specific Heat Capacity:
0.435 J/g-°C
Thermal Conductivity:
11.4 W/m-K
Elongation:
25 %
Product Name:
Nickel-based Alloy AMS 5596 Inconel 718 Nickel Alloy Plate/Nickel Tube For Aeronautical
Description
Innovative Heat Treatment Processes For Inconel 718 Tube Production



Innovative Heat Treatment Processes for Inconel 718 Tube Production


  • Inconel Series

Inconel 718 tubes are perfect for applications where a high-strength, lightweight material is needed to withstand extreme conditions. Made from a nickel-chromium alloy, these tubes offer excellent resistance to both corrosion and high-temperature environments. They are ideal for use in applications such as aerospace, defense, and power generation. Our seamless manufacturing process ensures that each tube is free from defects and has consistent properties throughout its length. We offer a range of sizes and configurations to meet the needs of our customers, and we are committed to providing exceptional customer service and support



Alloy 718 nickel tubing is an age-hardenable nickel-chromium-iron alloy also containing significant amounts of niobium, molybdenum, titanium and aluminum. It combines good corrosion resistance with extremely high strength. Typical applications include heat exchangers and O-rings.



Alloy 718 Tube  has excellent corrosion resistance to many media. This resistance, which is similar to that of other nickel-chromium alloys, is a function of its composition. Nickel contributes to corrosion resistance in many inorganic and organic, other than strongly oxidizing, compounds throughout wide ranges of acidity and alkalinity. It also is useful in combating chloride-ion stress-corrosion cracking. Chromium imparts an ability to withstand attack by oxidizing media and sulfur compounds. Molybdenum is known to contribute to resistance to pitting in many media.






  • Chemical Properties of Inconel 718 Tube

Element Limiting Chemical Composition (%)
Nickel (plus Cobalt) 50%-55%
Chromium 17%-21%
Niobium (plus Tantalum) 4.75%-5.50%
Molybdenum 2.80%-3.30%
Titanium 0.65%-1.15%
Aluminum 0.20%-0.80%
Cobalt 1% max
Carbon 0.08% max
Manganese 0.35% max
Silicon 0.35% max
Phosphorus 0.015% max
Sulfur 0.015% max
Boron 0.006% max
Copper 0.30% max
Iron Balance*






 Inconel 718 Tube Application



Components for liquid fueled rockets, rings, casings and various formed sheet metal parts for aircraft and land-based gas turbine engines, and cryogenic tankage. It is also used for fasteners and instrumentation parts.Oil field applications






  • ,Type we could offer
    AMS Number Alloy Type UNS Cross Ref. Spec Misc./Shape
    AMS 5590 Inconel 718 Nickel N07718 - Tubing Inconel 718
    AMS 5596 Foil Inconel 718 Nickel N07718 - Foil AMS 5596 Foil
    AMS 5596 Plate Inconel 718 Nickel N07718 - Plate AMS 5596 Plate
    AMS 5596 Sheet Inconel 718 Nickel N07718 - Sheet AMS 5596 Sheet
    AMS 5596 Strip Inconel 718 Nickel N07718 - Strip AMS 5596 Strip
    AMS 5597 Plate Inconel 718 Nickel N07718 - Plate AMS 5597 Plate
    AMS 5597 Sheet Inconel 718 Nickel N07718 - Sheet AMS 5597 Sheet
    AMS 5597 Strip Inconel 718 Nickel N07718 - Strip AMS 5597 Strip
    AMS 5662 Bar Inconel 718 Nickel N07718 - Bar AMS 5662 Bar
    AMS 5662 Custom Tube Inconel 718 Nickel N07718 - Custom Tube AMS 5662 Custom Tube
    AMS 5662 Ring Inconel 718 Nickel N07718 - Ring AMS 5662 Ring
    AMS 5663 Bar Inconel 718 Nickel N07718 - Bar AMS 5663 Bar
    AMS 5663 Custom Tube Inconel 718 Nickel N07718 - Custom Tube AMS 5663 Custom Tube
    AMS 5663 Ring Inconel 718 Nickel N07718 - Ring AMS 5663 Ring
    AMS 5664 Bar Inconel 718 Nickel N07718 - Bar AMS 5664 Bar
    AMS 5664 Custom Tube Inconel 718 Nickel N07718 - Custom Tube AMS 5664 Custom Tube
    AMS 5664 Ring Inconel 718 Nickel N07718 - Ring AMS 5664 Ring
    AMS 5832 Inconel 718 Nickel N07718 - Wire Inconel 718
    AMS 5962 Bar Inconel 718 Nickel N07718 - Bar AMS 5962 Bar
    AMS 5962 Wire Inconel 718 Nickel N07718 - Wire AMS 5962 Wire
  •
