Memory Alloy NiTi Tube OD 3mm ID 2mm Length 1000mm

Memory Alloy NiTi Tube OD 3mm ID 2mm Length 1000mm

Product Details:

Place of Origin: China
Brand Name: DLX
Model Number: NiTiNol

Payment & Shipping Terms:

Minimum Order Quantity: 15
Packaging Details: Spool package with Carton box, Coil package with polybag
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Get Best Price Contact Now

Detail Information

Material: Ni+Ti Fracture Elongation: ≥10%
Density: 6.45 G/cm3 Tensile Strength Rm N/mm²: ≥1000 MPa
Loading Plateau Stress: ≥ 380 MPa Austenite Finish Temperature(Af): ≤15 °C
Melting Point: 1310 Coefficient Of Thermal Expansion: 11×10-6 °K
Specific El. Resistivity: 82 μΩcm
High Light:

Memory Alloy NiTi Tube

,

OD 3mm NiTi Tube

,

ID 2mm NiTiNol Tube

Product Description

Memory Alloy NiTi Tube OD 3mm ID 2mm Length 1000mm 0

Memory alloy tube NiTi alloy OD 3mm ID 2mm length 1000mm for sale


What is NiTiNol alloy.



DLX alloy offer memory alloy products. And Nitinol tubing can be used as-is or laser cut into a discrete component, such as a stent or frame. The superelasticity and shape memory capabilities of this material make it great choice when developing a complex medical device.Nitinol is a kind of special unique material. No other material exhibits the mechanical shape memory superelasticity and the thermal shape memory effects. Fields of applications of Nitinol are peripheral stents, cardio stents and other medical devices for the human body. The name for the alloys composing it (Ni-nickel and Ti-titanium), along with the laboratory where it was discovered (the Naval Ordnance Laboratory), nitinol is also widely used in the aerospace, energy and industrial sectors.It is a term for binary near equal-atom Ni-Ti alloys, and it is widely used in medical due to its unique super-elasticity. However, Ternary or other Nickel-Titanium alloys can be achieved for different properties. All incoming Nitinol raw materials are subjected to third party inspection to ensure they meet proprietary specifications for chemistry, transformation temperature, material homogeneity, and microstructure.





NiTiNol Tube:

Our Nitinol tubes with the mechanical properties, requested tolerances and appropriate surface quality for stent use. All our Niti tubes are made according to customers specifications.





Nickel welding wire    Nickel welding wire    Nickel welding wire   Nickel welding wire   Nickel welding wire


Chemical Properties of NiTiNol Tube

el Welding Wire    Nickel W

Component Nickel Cobalt Iron Carbon Nioium Copper Chromium Oxygen + Nitrogen Hydrogen Titanium
wt % 54,50-57,00 max. 0,050 max. 0,050 max. 0,050 max. 0,025 max. 0,010 max. 0,010 max. 0,050 max. 0,005 balance

elding Wire    Nickel Welding Wire   Nickel Welding Wire


Mechanical / Superelastic Tubes Properties



Ultimate Tensile Strength Fracture Elongation Loading Plateau Stress (at 3% strain) Permanent Set (after 6% strain) Austenite Finish Temperature(Af)
min. 1000 MPa min. 10 % min. 380 MPa max. 0,3 % max. 15 °C





Physical Tube Properties



Melting Point Density Specific el. Resistivity Coefficient of Thermal Expansion (CTE) Modulus of Elasticity
1310 °C 6,5 g/cm3 82 μΩcm 11×10-6 °K 41-75 GPa







How can I contact with your company?
We are always ready to serve you via Email, Telephone, Fax, Skype, Whatsapp or Mobile
telephone.

What is your working time?
Monday-Saturday : 8:30AM-16:00PM (Beijing time, GMT+08.00)
We have public holiday during May.1-3, Oct.1-7 and Chinese New Year holiday . For detail,
please see our update holiday notice. During these period, if you have a demand, Please
send me an email.

Do you provide free samples?
Yes, we can provide a free sample for testing,buyer should bear all the shipping costs.

What is your payment terms?
T/T,L/C,D/A,D/P,Western Union,MoneyGram,Paypal
We are doing the best to match your demand.

What is the lead time?
Usually sample lead time is 7 days after payment has been confirmed.
Normal order is 10-30days,it depends on customers' quantity.
Anyway,we try to offer good-quality products as soon as possible.

Can you supply neutral packaging or labels with our company name?
Yes, please confirm on your requirements with your RFQ and order. Special packaging to individual requirements may also be available on request.

Memory Alloy NiTi Tube OD 3mm ID 2mm Length 1000mm 1Memory Alloy NiTi Tube OD 3mm ID 2mm Length 1000mm 2
