Product Details
Place of Origin: China
Brand Name: DLX
Model Number: NiTiNol
Payment & Shipping Terms
Minimum Order Quantity: 15
Packaging Details: Spool package with Carton box, Coil package with polybag
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Material: |
Ni+Ti |
Fracture Elongation: |
≥10% |
Density: |
6.45 G/cm3 |
Tensile Strength Rm N/mm²: |
≥1000 MPa |
Loading Plateau Stress: |
≥ 380 MPa |
Austenite Finish Temperature(Af): |
≤15 °C |
Melting Point: |
1310 |
Coefficient Of Thermal Expansion: |
11×10-6 °K |
Specific El. Resistivity: |
82 μΩcm |
Material: |
Ni+Ti |
Fracture Elongation: |
≥10% |
Density: |
6.45 G/cm3 |
Tensile Strength Rm N/mm²: |
≥1000 MPa |
Loading Plateau Stress: |
≥ 380 MPa |
Austenite Finish Temperature(Af): |
≤15 °C |
Melting Point: |
1310 |
Coefficient Of Thermal Expansion: |
11×10-6 °K |
Specific El. Resistivity: |
82 μΩcm |
What is NiTiNol alloy.
Nitinol is a kind of special unique material. No other material exhibits the mechanical shape memory superelasticity and the thermal shape memory effects. Fields of applications of Nitinol are peripheral stents, cardio stents and other medical devices for the human body. The name for the alloys composing it (Ni-nickel and Ti-titanium), along with the laboratory where it was discovered (the Naval Ordnance Laboratory), nitinol is also widely used in the aerospace, energy and industrial sectors.It is a term for binary near equal-atom Ni-Ti alloys, and it is widely used in medical due to its unique super-elasticity. However, Ternary or other Nickel-Titanium alloys can be achieved for different properties. All incoming Nitinol raw materials are subjected to third party inspection to ensure they meet proprietary specifications for chemistry, transformation temperature, material homogeneity, and microstructure. To promote an exceptionally smooth and uniform surface finish quality, all wire and tube products utilize a high precision single and/or multi crystalline diamond drawing die technology to reach the final wire diameter.
NiTiNol Tube:
Our Nitinol tubes with the mechanical properties, requested tolerances and appropriate surface quality for stent use. All our Niti tubes are made according to customers specifications.
Nickel welding wire Nickel welding wire Nickel welding wire Nickel welding wire Nickel welding wire
| Component | Nickel | Cobalt | Iron | Carbon | Nioium | Copper | Chromium | Oxygen + Nitrogen | Hydrogen | Titanium |
| wt % | 54,50-57,00 | max. 0,050 | max. 0,050 | max. 0,050 | max. 0,025 | max. 0,010 | max. 0,010 | max. 0,050 | max. 0,005 | balance |
elding Wire Nickel Welding Wire Nickel Welding Wire
| Ultimate Tensile Strength | Fracture Elongation | Loading Plateau Stress (at 3% strain) | Permanent Set (after 6% strain) | Austenite Finish Temperature(Af) |
| min. 1000 MPa | min. 10 % | min. 380 MPa | max. 0,3 % | max. 15 °C |
| Melting Point | Density | Specific el. Resistivity | Coefficient of Thermal Expansion (CTE) | Modulus of Elasticity |
| 1310 °C | 6,5 g/cm3 | 82 μΩcm | 11×10-6 °K | 41-75 GPa |
| How can I contact with your company? |
| We are always ready to serve you via Email, Telephone, Fax, Skype, Whatsapp or Mobile |
| telephone. |
| What is your working time? |
| Monday-Saturday : 8:30AM-16:00PM (Beijing time, GMT+08.00) |
| We have public holiday during May.1-3, Oct.1-7 and Chinese New Year holiday . For detail, |
| please see our update holiday notice. During these period, if you have a demand, Please |
| send me an email. |
| Do you provide free samples? |
| Yes, we can provide a free sample for testing,buyer should bear all the shipping costs. |
| What is your payment terms? |
| T/T,L/C,D/A,D/P,Western Union,MoneyGram,Paypal |
| We are doing the best to match your demand. |
| What is the lead time? |
| Usually sample lead time is 7 days after payment has been confirmed. |
| Normal order is 10-30days,it depends on customers' quantity. |
| Anyway,we try to offer good-quality products as soon as possible. |
| Can you supply neutral packaging or labels with our company name? |
| Yes, please confirm on your requirements with your RFQ and order. Special packaging to individual requirements may also be available on request. |
