AF 15 ℃ NiTiNol Tube For Medical Industry

Product Details

Place of Origin: China

Brand Name: DLX

Model Number: NiTiNol

Payment & Shipping Terms

Minimum Order Quantity: 15

Packaging Details: Spool package with Carton box, Coil package with polybag

Delivery Time: 5-21 days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 300 tons per month

Get Best Price
Contact Now
Specifications
Highlight:

AF 15 Degree NiTiNol Tube

,

Medical Industry NiTiNol Tube

Material:
Ni+Ti
Fracture Elongation:
≥10%
Density:
6.45 G/cm3
Tensile Strength Rm N/mm²:
≥1000 MPa
Loading Plateau Stress:
≥ 380 MPa
Austenite Finish Temperature(Af):
≤15 °C
Melting Point:
1310
Coefficient Of Thermal Expansion:
11×10-6 °K
Specific El. Resistivity:
82 μΩcm
Material:
Ni+Ti
Fracture Elongation:
≥10%
Density:
6.45 G/cm3
Tensile Strength Rm N/mm²:
≥1000 MPa
Loading Plateau Stress:
≥ 380 MPa
Austenite Finish Temperature(Af):
≤15 °C
Melting Point:
1310
Coefficient Of Thermal Expansion:
11×10-6 °K
Specific El. Resistivity:
82 μΩcm
Description
AF 15 ℃ NiTiNol Tube For Medical Industry

AF 15 ℃ NiTiNol Tube For Medical Industry 0

AF 15 ℃ NiTiNol Tube For Medical Industry


What is NiTiNol alloy.



Nitinol is a kind of special unique material. No other material exhibits the mechanical shape memory superelasticity and the thermal shape memory effects. Fields of applications of Nitinol are peripheral stents, cardio stents and other medical devices for the human body. The name for the alloys composing it (Ni-nickel and Ti-titanium), along with the laboratory where it was discovered (the Naval Ordnance Laboratory), nitinol is also widely used in the aerospace, energy and industrial sectors. Nitinol possesses critical physical and mechanical properties and offers elegant solutions to meet complex anatomical and physiological needs. Nitinol’s biocompatibility, kink resistance, superelasticity and ability to shape set, helps medical device designers to develop next-generation medical devices. From producing a cost-effective implant grade premium ID Nitinol tube (improving stent yield and cost control for stent producers) to excellent thickness control to create the thinnest sheet in the industry, JM is your trusted choice for Nitinol.





NiTiNol Tube:

Our Nitinol tubes with the mechanical properties, requested tolerances and appropriate surface quality for stent use. All our Niti tubes are made according to customers specifications.





Nickel welding wire    Nickel welding wire    Nickel welding wire   Nickel welding wire   Nickel welding wire


Chemical Properties of NiTiNol Tube

el Welding Wire    Nickel W

Component Nickel Cobalt Iron Carbon Nioium Copper Chromium Oxygen + Nitrogen Hydrogen Titanium
wt % 54,50-57,00 max. 0,050 max. 0,050 max. 0,050 max. 0,025 max. 0,010 max. 0,010 max. 0,050 max. 0,005 balance

elding Wire    Nickel Welding Wire   Nickel Welding Wire


Mechanical / Superelastic Tubes Properties



Ultimate Tensile Strength Fracture Elongation Loading Plateau Stress (at 3% strain) Permanent Set (after 6% strain) Austenite Finish Temperature(Af)
min. 1000 MPa min. 10 % min. 380 MPa max. 0,3 % max. 15 °C





Physical Tube Properties



Melting Point Density Specific el. Resistivity Coefficient of Thermal Expansion (CTE) Modulus of Elasticity
1310 °C 6,5 g/cm3 82 μΩcm 11×10-6 °K 41-75 GPa







How can I contact with your company?
We are always ready to serve you via Email, Telephone, Fax, Skype, Whatsapp or Mobile
telephone.

What is your working time?
Monday-Saturday : 8:30AM-16:00PM (Beijing time, GMT+08.00)
We have public holiday during May.1-3, Oct.1-7 and Chinese New Year holiday . For detail,
please see our update holiday notice. During these period, if you have a demand, Please
send me an email.

Do you provide free samples?
Yes, we can provide a free sample for testing,buyer should bear all the shipping costs.

What is your payment terms?
T/T,L/C,D/A,D/P,Western Union,MoneyGram,Paypal
We are doing the best to match your demand.

What is the lead time?
Usually sample lead time is 7 days after payment has been confirmed.
Normal order is 10-30days,it depends on customers' quantity.
Anyway,we try to offer good-quality products as soon as possible.

Can you supply neutral packaging or labels with our company name?
Yes, please confirm on your requirements with your RFQ and order. Special packaging to individual requirements may also be available on request.

AF 15 ℃ NiTiNol Tube For Medical Industry 1
