AWS A5.14 ErNiFe 6 Incoloy Alloy Welding Rod 3.2mm

Place of Origin China
Brand Name DLX
Model Number ErNiFe-6
Minimum Order Quantity 15
Packaging Details Spool package with Carton box, Coil package with polybag
Delivery Time 5-21 days
Payment Terms L/C, T/T, Western Union, MoneyGram
Supply Ability 300 tons per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

WeChat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Ni. Cr. Fe. Mn. Ti Elongation ≥30%
Tensile Strength Rm N/mm² 560mpa Grade ASME SFA 5.14 ErNiFe-6
Melting Point 1320-1370℃ Certificate ISO 9001
Highlight

Incoloy Alloy Welding Rod

,

ErNiFe 6 Alloy Welding Rod

,

AWS A5.14 Nickel Welding Wire

Leave a Message
Product Description



AWS A5.14 ErNiFe 6 Incoloy Alloy Welding Rod 3.2mm 0

Price of AWS A5.14 3.2mm ErNiFe-6 incoloy alloy welding rod for sales


Nickel Based Welding Wire
Nickel based welding wire ERNiCrFe-6  is used for shielded-metal-arc welding of INCOLOY alloys 800 and 800HT,INCONEL alloys 600 and 601, and nickel steels. ERNiCrFe-6 weld metal has excellent strength and oxidation resistance at high temperatures and retains impact resista nee at cryoge nic temperatures. Changzhou DLX alloy is one of the main producer in China for the ErNiCrFe-6 welding wire. ErNiCrFe properties are appropriate for the as-welded condition. Also ERNiCrFe-6 is the AWS designation for this material. N07092 is the UNS number.ErNiCrFe-6 also has a moderately low base cost among nickel-based welding fillers. In addition, it has a moderately low embodied energy and a moderately low melting temperature.The graph bars on the material properties cards below compare AWS ERNiCrFe-6 to: nickel-based welding fillers (top), all nickel alloys (middle), and the entire database (bottom). A full bar means this is the highest value in the relevant set. A half-full bar means it's 50% of the highest, and so on.


Nickel alloy Weling wire series:


ERNiCrMo-3,ERNiCrMo-4,ERNiCrMo-13,ERNiCrFe-3,ERNiCrFe-7,ERNiCr-3,ERNiCr-7,ERNiCu-7,ERNi-1, ER70S-6.

Standard: Conforms to Certification AWS A5.14 ASME SFA A5.14

Size: 0.8MM / 1.0MM / 1.2MM / 1.6MM / 2.4MM / 3.2MM / 3.8MM / 4.0MM / 5.0MM

Form: MIG(15kgs/spool), TIG(5kgs/box),Strip

Nickel welding wire    Nickel welding wire    Nickel welding wire   Nickel welding wire   Nickel welding wire


Chemical Properties of Nickel welding wire ErNiCrFe-6

Ni+Co Cr Fe Cu Ti Mn Si S P C Others
67 Min 14-17 8 max 0.5 max. 2.5-3.5. 2-2.7 0.35max 0.015 max. 0.03 Max 0.08 max. 0.5 Max


Size we could offer

MIG (15kg/spool), Size
    0.8 1.2 2.4 3.2mm
TIG (5kg/box),Strip



Application


ErNiCrFe-6 Filler Metal 92 is used for gas-tungsten-arc and gas-metal-arc welding of austenitic and ferritic steels and nickel alloys. Applications include joining INCONEL and INCOLOY alloys to stainless steels, carbon steels, and MONEL alloys; joining MONEL alloys and Nickel 200 to stainless steels; and joining stainless steels to carbon steels. The filler metal is also used for welding nickel steels. Filler Metal 92 provides high strength and corrosion resista nee at temperatures ranging from the cryogenic region to over 1800°F (980°C). Weld deposits can be age hardened for greater strength at temperatures to about 1300°F (700°C).



CHANGZHOU DLX ALLOY COMPANY was establish in 2016,our factory established in 2002 and has got ISO9001 International Quality Management System Certificate and SGS Certificate.Our factory is becoming a high-tech company,We are professional in researching and producing special alloy material.The production process include melting,drawing,heat treatment,finishing and testing.We offer super alloy,welding wire,corrosion resistance alloy,precision alloy,FeCrAl alloy,NiCr alloy,CuNi alloy,in the form of wire,strip,ribbon,bar,tube,plate and etc.The administrative principle of our company is "intensifying inner supervision, complying with technical process and quality control, continuously adopting new technology to ensure the product quality". We employ some senior engineers to instruct technology, apply new technology and research new products. Our operation principle is "Quality first, Customer first". All the staff of our company would like to provide high quality and reasonably priced products for clients at home and abroad, and to make your products more competitive.

How can I contact your company?

We are always ready to serve you via Email, Telephone, Fax, Skype, Whatsapp or Mobile

telephone.:+8618951230953



Contact Person:Johnny Chan

What is your working time?



Monday-Saturday : 8:30AM-18:00PM (Beijing time, GMT+08.00)

We have public holiday during May.1-3, Oct.1-7 and Chinese New Year holiday . Pls email us during our holiday if u have any question



Do you provide free samples?

Yes, we can provide a free sample for testing,buyer should bear all the shipping costs.







What is your payment terms?

T/T,L/C,D/A,D/P,Western Union,MoneyGram,Paypal







What is the lead time?

Usually sample lead time is 7 days after payment has been confirmed.
