Soft 760 MPA N06455 C4 ASTM B575 Nickel Chromium Molybdenum
Product Details:
| Place of Origin: | China |
| Brand Name: | DLX |
| Model Number: | Hastelloy C-4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 |
|---|---|
| Packaging Details: | Hastelloy C-4 strip packed in coil,then in woodencase |
| Delivery Time: | 5-21 days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 300 tons per month |
|
Detail Information |
|||
| Material: | Ni Cr Mo | Elongation: | 30 % |
|---|---|---|---|
| Brinell Hardness HB: | ≤220 | Density: | 8.89 G/cm3 |
| Tensile Strength Rm N/mm²: | 760MPA | Yieldstrength R P0. 2 N/mm²: | 345MPA |
| Electrical Resistivity（24℃））: | 1.30 Microhm-m | Thermal Conductivity（32℃）: | 9.4 W/m-K |
| Model Number: | Bright Soft Nickel Based Alloy Hastelloy C-4 Alloy Strip With Good Price | ||
| High Light: | N06455 Nickel Chromium Molybdenum,C4 Chrome Nickel Molybdenum Steel,ASTM B575 Nickel Chromium Molybdenum |
||
Product Description
- Nickel Based corrosion resistance Alloy
HASTELLOY® C-4 alloy (UNS N06455) is the most (microstructurally) stable of the widely used nickel-chromium-molybdenum materials, which are well known for their resistance to many aggressive chemicals, in particular hydrochloric acid, sulfuric acid, and chlorides. This stability means that the alloy can be welded without fear of sensitization, i.e. the nucleation and growth of deleterious, second phase precipitates in the grain boundaries of the weld heat-affected zone (HAZ).
Like other nickel alloys, it is ductile, easy to form and weld, and possesses exceptional resistance to stress corrosion cracking in chloride-bearing solutions (a form of degradation to which the austenitic stainless steels are prone). With its high chromium and molybdenum contents, it is able to withstand both oxidizing and non-oxidizing acids, and is resistant to pitting and crevice attack in the presence of chlorides and other halides.
-
Chemical Properties of Hastelloy C-4 Strip
| Hastelloy Alloy | Ni | Cr | Co | Mo | FE | W | Mn | C | V | P | S | Si |
| C-4 | Balance | 14-18 | 2 Max | 14-17 | 3.0 Max | 1.0 Max | 0.015 Max | 0.04 Max | 0.03 Max | 0.08 Max |
- Application
Some typical applications are:
- Strong oxidizers (such as ferric and cupric chlorides)
- Hot contaminated media (organic and inorganic)
- Chlorine
- Formic and acetic acids
- Acetic anhydride
- Seawater and brine solutions
- Type we could offer
| ASTM | Alloy | Type | UNS | Misc./Shape | |
| ASTM B574 Bar |
Hastelloy C-4 | Nickel | N06455 | Bar | |
| ASTM B575 Plate |
Hastelloy C-4 | Nickel | N06455 | Plate | |
| ASTM B575 Strip |
Hastelloy C-4 | Nickel | N06455 | Strip | |
| ASTM B575 Sheet |
Hastelloy C-4 | Nickel | N06455 | Sheet | |
| ASTM B619 Welded Pipe |
Hastelloy C-4 | Nickel | N06455 | Welded Pipe | |
| ASTM B622 Seamless Tubing |
Hastelloy C-4 | Nickel | N06455 | Seamless Tubing | |
| ASTM B366 Fittings |
Hastelloy C-4 | Nickel | N06455 | Fittings | |
| ASTM B574 Wire |
Hastelloy C-4 | Nickel | N06455 | Wire |
