Product Details:

Place of Origin: China
Brand Name: DLX
Model Number: Hastelloy C22 Rod

Payment & Shipping Terms:

Minimum Order Quantity: 5
Packaging Details: Hastelloy C276 Bar packed in wooden case
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Get Best Price Contact Now

Detail Information

Material: Ni Cr Mo Elongation: 30 %
Brinell Hardness HB: ≤220 Density: 8.89 G/cm3
Tensile Strength Rm N/mm²: 760MPA Yieldstrength R P0. 2 N/mm²: 345MPA
Electrical Resistivity(24℃)): 1.30 Microhm-m Thermal Conductivity(32℃): 9.4 W/m-K
Product Name: Hastelloy C-22 C22 Hastelloy C22 Hastelloy C-22 Nickel Round Bar N06022 Special Alloy C22 Bar
High Light:

C276 Hastelloy Alloy

,

760 MPA Hastelloy Stainless Steel

,

UNS N1022 Hastelloy Alloy

Product Description

C276 Hastelloy Alloy 0


C276 Hastelloy Alloy 1


  • Nickel Based corrosion resistance Alloy

Hastelloy C276 Bar UNS N1022) was the first wrought, nickel-chromium-molybdenum material to alleviate concerns over welding (by virtue of extremely low carbon and silicon contents). As such, it was widely accepted in the chemical process and associated industries, and now has a more than 50-year-old track record of proven performance in a vast number of corrosive chemicals.

Like other nickel alloys, it is ductile, easy to form and weld, and possesses exceptional resistance to stress corrosion cracking in chloride-bearing solutions (a form of degradation to which the austenitic stainless steels are prone). With its high chromium and molybdenum contents, it is able to withstand both oxidizing and non-oxidizing acids, and exhibits outstanding resistance to pitting and crevice attack in the presence of chlorides and other halides. Furthermore, it is very resistant to sulfide stress cracking and stress corrosion cracking in sour, oilfield environments








  • Chemical Properties of Hastelloy C22 Bar

Hastelloy Alloy Ni Cr Co Mo FE W Mn C V P S Si
C22 Balance 20-22.5 2.5 Max 12.5-14.5 2.0-6.0 2.5-3.5 0.5Max 0.015 Max 0.35 Max 0.04 Max 0.03 Max 0.08 Max








  • Application


Some typical applications are:

  • Strong oxidizers (such as ferric and cupric chlorides)
  • Hot contaminated media (organic and inorganic)
  • Chlorine
  • Formic and acetic acids
  • Acetic anhydride
  • Seawater and brine solutions






  • Type we could offer
ASTM Alloy Type UNS Misc./Shape
ASTM B574
Bar
Hastelloy C22 Nickel N10276 Bar C276 Hastelloy Alloy 2
ASTM B575
Plate
Hastelloy C22 Nickel N10276 Plate C276 Hastelloy Alloy 3
ASTM B575
Strip
Hastelloy C22 Nickel N10276 Strip C276 Hastelloy Alloy 4
ASTM B575
Sheet
Hastelloy C22 Nickel N10276 Sheet C276 Hastelloy Alloy 5
ASTM B619
Welded Pipe
Hastelloy C22 Nickel N10276 Welded Pipe C276 Hastelloy Alloy 6
ASTM B622
Seamless Tubing
Hastelloy C22 Nickel N10276 Seamless Tubing C276 Hastelloy Alloy 7 C276 Hastelloy Alloy 8
ASTM B366
Fittings
Hastelloy C22 Nickel N10276 Fittings C276 Hastelloy Alloy 9
ASTM B574
Wire
Hastelloy C22 Nickel N10276 Wire
