Hastelloy C276 UNS N10276 B574 Nickel Chromium Molybdenum

Name: Hastelloy C276 UNS N10276 B574 Nickel Chromium Molybdenum
Brand: Changzhou DLX Alloy Co., Ltd.
SKU: Hastelloy C276
Price: 149.30 USD
Availability: InStock

Brand Name:	DLX
Model Number:	Hastelloy C276
MOQ:	5
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China Jiangsu

Certification:

CE,ROHS

Material:

Ni Cr Mo

Elongation:

30 %

Brinell Hardness HB:

≤220

Density:

8.89 G/cm3

Tensile Strength Rm N/mm²:

760MPA

Yieldstrength R P0. 2 N/mm²:

345MPA

Electrical Resistivity（24℃））:

1.30 Microhm-m

Thermal Conductivity（32℃）:

9.4 W/m-K

Packaging Details:

Spool package with Carton box, Coil package with polybag

Supply Ability:

500 tons per month

Highlight:

Hastelloy C276 Nickel Chromium Molybdenum

UNS N10276 Chromium Molybdenum

B574 Nickel Chromium Molybdenum

Product Description

Hastelloy C276 UNS N10276 B574 Nickel Chromium Molybdenum 0

Hastelloy C276 UNS N10276 B574 Nickel Chromium Molybdenum 1

Nickel Based corrosion resistance Alloy

HASTELLOYC-276 UNS N10276) was the first wrought, nickel-chromium-molybdenum material to alleviate concerns over welding (by virtue of extremely low carbon and silicon contents). As such, it was widely accepted in the chemical process and associated industries, and now has a more than 50-year-old track record of proven performance in a vast number of corrosive chemicals.

Like other nickel alloys, it is ductile, easy to form and weld, and possesses exceptional resistance to stress corrosion cracking in chloride-bearing solutions (a form of degradation to which the austenitic stainless steels are prone). With its high chromium and molybdenum contents, it is able to withstand both oxidizing and non-oxidizing acids, and exhibits outstanding resistance to pitting and crevice attack in the presence of chlorides and other halides. Furthermore, it is very resistant to sulfide stress cracking and stress corrosion cracking in sour, oilfield environments

Chemical Properties of Hastelloy C276

Hastelloy Alloy

C276

Balance

14.5-16.5

2.5 Max

15.0-17.0

4.0-7.0

3.0-4.5

1.0 Max

0.01 Max

0.35 Max

0.04 Max

0.03 Max

0.08 Max

Application

Some typical applications are:

Strong oxidizers (such as ferric and cupric chlorides)
Hot contaminated media (organic and inorganic)
Chlorine
Formic and acetic acids
Acetic anhydride
Seawater and brine solutions

Type we could offer

ASTM	Alloy	Type	UNS	Misc./Shape
ASTM B574 Bar	Hastelloy C276	Nickel	N10276	Bar
ASTM B575 Plate	Hastelloy C276	Nickel	N10276	Plate
ASTM B575 Strip	Hastelloy C276	Nickel	N10276	Strip
ASTM B575 Sheet	Hastelloy C276	Nickel	N10276	Sheet
ASTM B619 Welded Pipe	Hastelloy C276	Nickel	N10276	Welded Pipe
ASTM B622 Seamless Tubing	Hastelloy C276	Nickel	N10276	Seamless Tubing
ASTM B366 Fittings	Hastelloy C276	Nickel	N10276	Fittings
ASTM B574 Wire	Hastelloy C276	Nickel	N10276	Wire
