Shielding Braid Thermocouple Compensation Cable Type J K T E S For Temperature Environments

Name: Shielding Braid Thermocouple Compensation Cable Type J K T E S For Temperature Environments
Brand: Changzhou DLX Alloy Co., Ltd.
SKU: Thermocouple Bare Wire
Price: 1.50 USD
Availability: InStock

Brand Name:	DLX
Model Number:	Thermocouple Bare Wire
MOQ:	5kg
Price:	$1.5-2
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	300 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO SGS

Supply Ability:

300 tons per month

Highlight:

Temperature Environments Thermocouple Compensation Cable

Shielding Braid Thermocouple Compensation Cable

J Shielding Braid Thermocouple Compensation Cable

Product Description

Key attributes

Other attributes

Place of Origin

Jiangsu, China

Brand Name

DLX

Product name

K Thermocouple Extension Compensation Cable

Surface

Bright/Oxidized

Standard

IEC 584, ASTM

Size

Customized Size

Chemical composition

NiCr,NiSi

Application

Cable & Wire

Packing

on spool or as coil

Certificate

ISO

M.O.Q.

50m

Delivery time

5-15 Days

Packaging and delivery

Selling Units:

Single item

Single package size:

20X15X10 cm

Single gross weight:

2.000 kg

Shielding Braid Thermocouple Compensation Cable Type J K T E S For Temperature Environments 0

Thermocouple Extension Compensation Cable

Name: Sheath Wire Type K
Type: K, N, E, J, T
Conductor material: NiCr-NiSi, NiCrSi-NiSi), NiCr-Konstantan, Fe Konstantan, Cu Konstantan
Insulator: 99.6% high purity MgO
Core number: 2, 4, 6
Sheath material: SS321(SS304), SS316, SS310, INCL600, Nicrobell
Dia(mm): from 0.25mm to 12.7mm
Application: connecting with thermocouple and instrument machine
Place of Origin: Jiangsu, China (Mainland)
MOQ: 100m
Certificate: ISO,CQC

Specification

Specifications		Grade	Working temperature (deg)		Tolerance	Standard
Product name	K type thermocouple wire		Long Term	Short Term
Size	2x0.2mm², 2x0.5mm²,2x1mm²,2x1.5mm² and etc...	1	-40~1100	-40~1300	±1.5 deg	GB/T 2614-1998
Conductor	Cu-CuNi/ NiCr-NiSi	2			±2.5 deg
Insulation	Fiberglass/PVC/FEP/SILICONE	1	-40~800	-40~900	±1.5 deg	GB/T 4993-1998
Shielding	stainless steel shielded,or copper shielded	2			±2.5 deg
Operating temperature	-200°C-800°C	1	-40~600	-40~800	±1.5 deg	GB/T 4994-1998
Color	IEC Color code	2			±2.5 deg
Packing	100m/roll	1	-200~300	-200~400	±0.5 deg	GB/T 2903-1998

Shielding Braid Thermocouple Compensation Cable Type J K T E S For Temperature Environments 2

Shielding Braid Thermocouple Compensation Cable Type J K T E S For Temperature Environments 3

Shielding Braid Thermocouple Compensation Cable Type J K T E S For Temperature Environments 4

Shielding Braid Thermocouple Compensation Cable Type J K T E S For Temperature Environments 5
