| Brand Name: | DLX |
| Model Number: | Platinum Iridium Wire |
| MOQ: | 10kg |
| Payment Terms: | Western Union,T/T,D/P,D/A,L/C,VTB |
| Supply Ability: | 500 tons per month |
In industries where precision and reliability are non-negotiable, material selection becomes a critical decision. Platinum Iridium alloy wire stands out as a premium solution, especially when electrical conductivity, corrosion resistance, and long-term stability are required at the same time.
At DLX, we focus on delivering high-performance alloy materials that solve real engineering challenges. Our Platinum Iridium alloy wire with 9.4*10⁶ S/m electrical conductivity is designed for applications where even the smallest deviation can lead to failure.
Product OverviewPlatinum Iridium alloy is a combination of platinum (Pt) and iridium (Ir), typically with iridium content ranging from 5% to 20%. This alloy retains the excellent corrosion resistance and chemical stability of platinum while significantly improving hardness and mechanical strength through the addition of iridium.
One of its standout properties is its stable electrical conductivity of approximately 9.4*10⁶ S/m, making it suitable for precision electrical and electronic applications where consistent signal transmission is essential.
At DLX, we manufacture this alloy wire using advanced melting, drawing, and annealing processes to ensure uniform composition, smooth surface finish, and tight dimensional control.
Key Features:Platinum Iridium alloy wire is widely used in industries that demand both electrical performance and material stability.
Used in implantable devices such as pacemaker electrodes, neurostimulation leads, and surgical instruments due to its biocompatibility and corrosion resistance.
Applied in high-precision sensors, thermocouples, and microelectronic components where stable conductivity is essential.
Used in high-reliability electrical contacts and components exposed to extreme temperatures and harsh environments.
Ideal for electrodes and catalyst supports in highly corrosive chemical environments.
Commonly used in analytical instruments and research setups requiring chemically inert conductive materials.
Inconsistent conductivity can lead to inaccurate readings and system failure.
DLX Solution:Our Platinum Iridium alloy wire provides stable and reliable electrical conductivity, ensuring accurate signal transmission over time.
Many conductive materials corrode or oxidize, leading to performance loss.
DLX Solution:With its noble metal composition, our alloy resists corrosion even in highly aggressive environments.
Pure platinum is soft and prone to deformation.
DLX Solution:The addition of iridium significantly enhances hardness and wear resistance, extending service life.
Material failure in medical devices can have serious consequences.
DLX Solution:Our alloy offers excellent biocompatibility and long-term stability, making it ideal for implantable applications.
Understanding the key parameters helps engineers choose the right material for their applications.
Measured in Siemens per meter (S/m), this indicates how well the material conducts electricity. A value of 9.4*10⁶ S/m ensures stable electrical performance.
Indicates the maximum stress the wire can withstand before breaking. Higher strength improves durability.
Determines resistance to deformation and wear. Platinum Iridium is significantly harder than pure platinum.
The ability to withstand chemical attack, which is critical in harsh environments.
Ensures consistent performance under temperature fluctuations.
| Property | Platinum Iridium Alloy Wire |
|---|---|
| Electrical Conductivity | 9.4*10⁶ S/m |
| Density | 21.5 g/cm³ |
| Melting Point | ~1800°C |
| Tensile Strength | 500–900 MPa |
| Elongation | ≥ 10% |
| Hardness | High |
| Operating Temperature | Up to 1000°C |
| Corrosion Resistance | Excellent |
| Feature | Pt-Ir Alloy Wire | Standard Conductive Wire |
|---|---|---|
| Electrical Stability | Excellent | Variable |
| Corrosion Resistance | Superior | Moderate |
| Mechanical Strength | High | Low to Medium |
| Wear Resistance | High | Limited |
| Service Life | Long | Shorter |
| Cost Efficiency | High lifecycle value | Lower initial cost |
While standard conductive materials may be cheaper initially, they often fail in demanding environments. Platinum Iridium alloy wire offers a much longer service life and consistent performance, making it more cost-effective over time.
DLX Company AdvantageAt DLX, we don’t just supply materials—we provide reliable solutions tailored to your application.
Our 12,000㎡ factory is equipped with complete capabilities for research, production, testing, and packaging. We strictly adhere to ISO 9001 standards in our production processes, with an annual output of 1,200 tons. This ensures that we meet both quantity and quality demands. Furthermore, all products undergo rigorous simulated environment testing including high temperature, high pressure, and corrosion tests before being dispatched, ensuring they meet customer specifications.For all our clients, we offer timely and multilingual after-sales support and technical consulting, helping you resolve any issues swiftly and efficiently.
Client Visits
Building Stronger Partnerships
We support all kinds of testing:
Frequently Asked Questions
In high-precision industries, reliability is everything. Platinum Iridium alloy wire offers the performance, durability, and stability required for the most demanding applications. At DLX, we ensure every product meets these expectations and delivers consistent results.
We can provide customized solutions.
