DLX N4 N6 Pure Nickel Strips with High Conductivity & Low Vapor Pressure

Product Details

Place of Origin: China

Brand Name: DLX

Certification: CE,ROHS

Model Number: ni200 ni201 Pure Nickel strip

Payment & Shipping Terms

Minimum Order Quantity: 2kg

Packaging Details: Spool package with Carton box, Coil package with polybag for pure nickel strip

Delivery Time: 5-21 days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 300 tons per month

Get Best Price
Contact Now
Specifications
Highlight:

N6 Nickel Strips

,

N4 Nickel Strips

,

N4 Nickel Strip For Battery

Product Name:
Pure Nickel Strip
Grade:
200 201 N4 N6
Certificate:
ISO9001,ROHS
Material:
Ni
Ni(min):
99%
Application::
Battery Pack, Industry
Size::
Customized
Atomic Weight:
58.6934 G/mol
Block:
D-block
Boiling Point:
2730 °C
Crystal Structure:
Cubic
Density:
8.9 G/cm3
Electron Configuration:
[Ar] 3d8 4s2
Form:
Solid
Group Name:
Transition Metals
Melting Point:
1455 °C
Product Name:
Pure Nickel Metal
Product Name:
Pure Nickel Strip
Grade:
200 201 N4 N6
Certificate:
ISO9001,ROHS
Material:
Ni
Ni(min):
99%
Application::
Battery Pack, Industry
Size::
Customized
Atomic Weight:
58.6934 G/mol
Block:
D-block
Boiling Point:
2730 °C
Crystal Structure:
Cubic
Density:
8.9 G/cm3
Electron Configuration:
[Ar] 3d8 4s2
Form:
Solid
Group Name:
Transition Metals
Melting Point:
1455 °C
Product Name:
Pure Nickel Metal
Description
DLX N4 N6 Pure Nickel Strips with High Conductivity & Low Vapor Pressure



DLX N4 N6 Pure Nickel Strips with High Conductivity & Low Vapor Pressure 0

DLX N4 N6 Pure Nickel Strips with High Conductivity & Low Vapor Pressure 1



DLX N4 N6 Pure Nickel Strips with High Conductivity & Low Vapor Pressure



Pure nickel strip nickel foil for battery spot welding

In addition to corrosion resistance, pure nickel strips exhibit excellent electrical conductivity. Nickel is known for its low electrical resistance, allowing for efficient transmission of electricity. This property makes pure nickel strips widely used in electronics, battery packs, and other electrical applications where high conductivity is crucial.

Dimension:
The thickness and dimensions can be met what customers required.
1. Material: pure nickel or nickel steel
2. Width: 2, 3, 4, 5, 6, 7, 8, 10, 15mm or customized width
3. Thickness: hot sale are 0.15mm/0.2mm, or customized thickness
4. Used for 18650, 26650, ,21700,32650, 32700 battery pack
4. Color: silver
5. 18650 nickel strip: 1P, 2P, 3P, 4P, 5P, 6P, 7P, 8P, 9P
26650 nickel strip: 1P, 2P, 3P, 4P, 5P, 6P, 7P, 8P, 9P
32650 nicekl strip: 1P, 2P, 3P, 4P, 5P



Physical properties
1.Spot welding is good
2.The resistance is lower
3. Battery discharge time longer
4. The battery spot welding is stronger.

Functions/Applications
1. manufacturing nickel-cadmium battery
2. nickel-hydrogen battery
3. lithium cell
4. assembled battery
5. industries of electric tool and special lights
6. Superconductor Applications
Grade Chemical Composition(%)
Ni+Co Cu Si Mn C Mg S P Fe
N4/201 99.9 ≤0.015 ≤0.03 ≤0.002 ≤0.01 ≤0.01 ≤0.001 ≤0.001 ≤0.04
N6/200 99.5 0.1 0.1 0.05 0.1 0.1 0.005 0.002 0.1

Material
18650/21700/26650/32650 nickel strip
Dimension
1P to 9P
Available Space
18.5mm,19mm, 19.5mm, 20.2mm
Usage
Use for 18650 battery pack
Package
Nickel strip in roll pack into carton
Physical properties
High temperature resistant, corrosion resistance,
Technical support
With imported stamping machine, Japanese Sodick, complete mold (more than 2000 sets of battery industry hardware mold), and can
open mold independently.
Functions
Products are widely used in energy storage battery, new energy vehicles, electric bicycles, solar street lights, power tools and
other energy products
Advantage
All materials are degreased and adopt the dry -punching technology to ensure that the product is clean

Size range

Wire: 0.025 to 8.0 mm.

Strip:0.05-1mm * 5-240mm

The thickness and dimensions can be met what customers required.





Physical properties
1.Spot welding of pure nickel is good
2.The resistance of pure nickel is lower
3. Battery discharge time of pure nickel strip longer
4. The battery spot welding is stronger.



Pure nickel Functions/Applications
1. manufacturing nickel-cadmium battery
2. nickel-hydrogen battery
3. lithium cell
4. assembled battery
5. industries of electric tool and special lights
6. Superconductor Applications

DLX N4 N6 Pure Nickel Strips with High Conductivity & Low Vapor Pressure 2DLX N4 N6 Pure Nickel Strips with High Conductivity & Low Vapor Pressure 3
