Low/Medium Magnetic Permeability/Low Coercive Force Alloy FeNi 85/Ni80Mo5 Strip

Name: Low/Medium Magnetic Permeability/Low Coercive Force Alloy FeNi 85/Ni80Mo5 Strip
Brand: Changzhou DLX Alloy Co., Ltd.
SKU: 1j85
Price: 42.00 USD
Availability: InStock

Brand Name:	DLX
Model Number:	1j85
MOQ:	1
Price:	$30-$55
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	200 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Material::

NiFe

Certificate:

ISO9001

Shape:

Wire, Strip, Foil, Sheet

Resistivity::

0.56

Density::

8.75g/cm3

Size:

Customized

Standard::

GB/ASTM/AISI/ASME

Condition::

Bright, Annealed, Soft

Application::

Industrial Magnet

Curie Point::

400℃

HCR::

Feature::

High Initial Permeability

Packaging Details:

Standard Export Wooden Cases Ex.Gross Weight Under 20kg=Carton Box/Gross Weight over 20 kg=Plywood Box Or as per Request for 1j85

Supply Ability:

200 tons per month

Highlight:

Soft Magnetic Alloy Strip

1J85 Ferro Nickel Alloy

FeNi 85 Magnetic Alloy Strip

Product Description

Low/Medium Magnetic Permeability/Low Coercive Force Alloy FeNi 85/Ni80Mo5 Strip 0

Low/Medium Magnetic Permeability/Low Coercive Force Alloy FeNi 85/Ni80Mo5 Strip 1

Soft Magnetic Alloy Strip 1J85 ferro nickel alloy / FeNi 85 / Ni80Mo5

Mainly used in two areas for energy conversion and information processing

In the power industry, mainly in the high magnetic field has a high magnetic induction and low core loss of the alloy. In the electronics industry, mainly at low or medium alloy having a high magnetic permeability and low coercive force. At high frequencies shall be made on a thin strip or alloy higher resistivity. Usually with sheet or strip.

Soft magnetic materials in exchange for use, due to the alternating magnetic eddy currents are induced inside the material, resulting in the loss, the smaller the resistance of the alloy, the greater the thickness, the higher the frequency of the alternating magnetic field, eddy current losses greater, magnetic reduce more. For this, the material must be made thinner sheet (tape), and the surface coated with an insulating layer, or the use of certain methods to the surface to form an oxide insulating layer, such alloys commonly used magnesium oxide electrophoresis coating.

Iron-nickel alloy mostly in the alternating magnetic field use, mainly for yoke iron, relay, Small Power Transformers and Magnetically shielded.

precision alloy precision alloy precision alloy

Low/Medium Magnetic Permeability/Low Coercive Force Alloy FeNi 85/Ni80Mo5 Strip 2

The Chemical Composition of Supermalloy

Grade	C≤	P≤	S≤	Cu≤	Si	Mn	Mo	Ni	Fe
1J85	0.03	0.02	0.02	0.20	0.15~0.3	0.30~0.60	4.80~5.20	79.0~81.0	Banlance

The Physical Property of Supermalloy

Grade	Resistivity(μΩ.m)	Density(g/cm3)	Curie Point ℃	High Saturated magneto-striction coefficient λθ/10-6
1J85	0.56	8.75	400	0.5

Application of Supermalloy

Precision Supermalloy alloy is used in manufacturing components for radio engineering,telephony and telemechanics instruments.

Low/Medium Magnetic Permeability/Low Coercive Force Alloy FeNi 85/Ni80Mo5 Strip 3

PRODUCT APPLICATION

Permalloy

Permalloy is used in transformer laminations and magnetic recording head sensors,in its initial application,permalloy was wrapped around the insulated copper conductors of telecommunication cables,reducing signal distortion through improved inductive compensation of cable capacitive reactance.

mumetal

High performance magnetic cores such as toroids and stacked laminations

Magnetic shielding to protect sensitive components from extraneous magnetic fields

Magnetic sensors

Current sensors

Any delicate application requiring high permeability magnetic material, with a low coercive field and low losses, in the range from low frequency up to 1MHz
