Ni95al5 Tafa 75B Thermal Arc Spray Wire Abrasion Resistant
|Place of Origin:||China|
Payment & Shipping Terms:
|Minimum Order Quantity:||15|
|Packaging Details:||Spool package with Carton box, Coil package with polybag|
|Delivery Time:||5-21 days|
|Payment Terms:||L/C, T/T, Western Union, MoneyGram|
|Supply Ability:||300 tons per month|
|Product Name:||Thermal Spray Wire||Grade:||Ni95Al5|
|Application:||Vacuum Coating||Coating Hardness:||HRB 75|
|Bonding Strength:||68.95 N/mm2|
Tafa 75B Thermal Arc Spray Wire,
Ni95al5 Thermal Arc Spray Wire,
Abrasion Resistant Thermal Spray Wire
Good Quality Ni95al5 Tafa 75B Thermal Spray Wire From Manufacturer
- Thermal spray wire
NiAl95/5 is a solid wire specifically designed for arc spray systems. It is self-bonding to most materials and requires minimal surface preparation. Bond strengths in excess of 9000 psi can be achieved on clean smooth surfaces. Roughening of the surface by machining, grit blasting or grinding can increase the bond strength up to 10,000 psi. NiAl95/5 exhibits good resistance to high temperature oxidation and abrasion, and excellent resistance to impact and bending. NiAl95/5 can be machined and ground to a finish of 5 micro inches. It is a self-bonding, one step material and is also suitable for the build-up and dimensional restoration of nickel-based alloys. PMET 885 is widely used as a bond coat for subsequent thermal spray topcoats and as a one-step build up material for dimensional restoration of aircraft engines.
Typical Uses and Applications:
This material has proven very effective in providing long term protection to boiler tubes against high temperature sulfidation. The wrought material is highly resistant to sulfur/vanadium atmospheres up to 1800°F. Wrought material of this type has shown a 2 mil per year corrosion rate over a nine year period when used in the super heater section of boilers. Coatings of 45CT wire applied to boiler tubes have shown virtually no loss of thickness or spalling after 24 months of service (as of this writing).
- Thermal spray wire
|Item||Inconel 625||Ni95Al5||45CT||Monel 400||HC-276||Cr20Ni80||K500|
(1) For vacuum coating
(2) For making valves grid, inner components of vacuum valves
(3) Components insides the electron tubes
(4) For making lead, supporting wire
(5) For Electronic components
(6) For battery production
(7) Strong base of the filter
- Size range
Wire: 0.8mm 1.2mm 1.6mm 2.4mm 3.2mm.
Products are generally supplied in standard cardboard boxes, pallets, wooden boxes. Special packaging requirements can also be accommodated. (also depend on the customers' requirements)
For the Thermal spray wires , we wind small size wire less than 1.6mm wires on spools. Bigger size over than 2.4mm in coils. Then put spools into cartons, Then put the cartons onto pallet or wood box.
- Our Services
1) Free sample could be supplied for testing purpose.
2) Customized lable, packing, OEM service.
3) Mill test certificate will be provided after production.
4) Good packing methods to keep goods statable.
