0.12mm Bright Surface Coating Acr 45CT Thermal Spray Wire

Name: 0.12mm Bright Surface Coating Acr 45CT Thermal Spray Wire
Brand: Changzhou DLX Alloy Co., Ltd.
SKU: 45CT
Price: 4.00 USD
Availability: InStock

Brand Name:	DLX
Model Number:	45CT
MOQ:	15
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	300 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

Thermal Spray Wire

Grade:

45CT

Certificate:

ISO9001

Material:

Ni Cr

Bonding Strength:

48.26 N/mm2

Deposit Rate:

10 Lbs/hr/100A

Coating Hardness:

HRC 30-35

Packaging Details:

Spool package with Carton box, Coil package with polybag

Supply Ability:

300 tons per month

Highlight:

Acr Thermal Spray Wire

0.12mm Nickel Base Alloy

45CT Thermal Spray Wire

Product Description

0.12mm Bright Surface Coating Acr 45CT Thermal Spray Wire 0

Thermal spray wire

Introduction:

NiCrTi/45CT wire is a Nickel/Chrome/Titanium wire developed specifically for boiler applications. This second generation material replaces 06BXP and produces coatings which are extremely resistant to corrosive vanadium and sulfur gases in boiler atmospheres.

Typical Uses and Applications:
This material has proven very effective in providing long term protection to boiler tubes against high temperature sulfidation. The wrought material is highly resistant to sulfur/vanadium atmospheres up to 1800°F. Wrought material of this type has shown a 2 mil per year corrosion rate over a nine year period when used in the super heater section of boilers. Coatings of 45CT wire applied to boiler tubes have shown virtually no loss of thickness or spalling after 24 months of service (as of this writing).

0.12mm Bright Surface Coating Acr 45CT Thermal Spray Wire 1

Thermal spray wire

Item	Inconel 625	Ni95Al5	45CT	Monel 400	HC-276	Cr20Ni80	K500
C	≤0.05	≤0.02	0.01-0.1	≤0.04	≤0.02	≤0.08	≤0.25
Mn	≤0.4	≤0.2	≤0.2	2.5-3.5	≤1.0	≤0.06	≤1.5
P	≤0.01	≤0.01	≤0.01	≤0.01	≤0.01	≤0.02	≤0.01
S	≤0.01	≤0.01	≤0.01	≤0.01	≤0.01	≤0.01	≤0.01
Si	≤0.15	≤0.2	≤0.2	≤0.15	≤0.08	0.75-1.6	≤0.5
Cr	21.5-23	≤0.2	42-46	-	14.5-16	20-23	-
Ni	Rest	Rest	Rest	65-67	Rest	Rest	Rest
Cu	-	-	-	Rest	-	-	27-33
Mo	8.5-10	-	-	-	15-17	-	-
Ti	≤0.4	0.4-1	0.3-1.0	2.0-3.0	-	-	0.35-0.85
Al	≤0.4	4--5	-	≤0.5	-	-	2.3-3.15
Fe	≤1.0	-	≤0.5	≤1.0	4.0-7.0	-	≤1.0
Nb	3.5-4.15	-	-	-	-	≤1.0	-
Co	-	-	-	-	-	-	-
V	-	-	-	-	≤0.35	-	-
W	-	-	-	-	3.0-4.5	-	-
Impurities	≤0.50	≤0.50	≤0.50	≤0.50	≤0.50	≤0.50	≤0.50

Application

Infrastructure such as bridges, trestles, water towers, wind turbines, pipelines
Marine and offshore applications, such as bridges, hulls for ships and tankers, offshore wind turbines
Corrosion Under Insulation (CUI)
Boilers and Digesters

Size range

Wire: 0.12 to 8.0 mm.
