4j36 Precision Alloy

4j36 Precision Alloy

Product Details:

Place of Origin: China
Brand Name: DLX
Model Number: invar 36

Payment & Shipping Terms:

Minimum Order Quantity: 10
Price: $20-$40
Packaging Details: packed with carton &polybag
Delivery Time: 7-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Get Best Price Contact Now

Detail Information

Certificate: ISO9001 Shape: Sheet
Ni (Min): 35 Size: Customized
Color: Nickel,silver Ultimate Strength (≥ MPa):: 490
Elongation (≥ %): 42 % Brand Name:: DLX
Density:: 8.1 Yield Strength:: 240
Standard:: ASTM, ASME, GB, DIN Etc
High Light:

K93600 Precision Alloy

,

Invar 36 Iron Nickel Alloy

,

4j36 Nickel Plate Precision Alloy

Product Description

4j36 Precision Alloy 0


4j36 Precision Alloy 1


  • Precisional alloy Ferronickel Invar 36 4J36 Nickel Plate





Precision alloy Invar 36, also known as FeNi36, is a nickel-iron, low-expansion alloy containing 36% nickel. Precision alloy invar 36  has a low coefficient of expansion from cryogenic temperatures to about 260°C. In the dry air at home temperature, precision alloy invar 36 has good resistance to corrosion. But precision ally invar 36 moist air, it may go corrosion.



Precision alloy Invar 36 is suitable for the applications who require low coefficient of expansion, such as production, storage and transportation of liquid gas, temperature regulation devices working below 200°C, aperture mask, unit frameworks working below -200°C and so on.





Product sizes are:



Invar Wire: 0.1mm-9mm
Invar Bar: 11mm-200mm
Invar Strip: 0.1mm-4.0mm*10mm-290mm
Sheets, Discs are also available per request





Precison alloy prcecision alloy precision alloy precision alloy



Chemical Composition

Grade C% Si% P% S% Mn% Ni% Fe%
Invar 36 Max 0.05 Max 0.30 Max 0.020 Max 0.020 0.20-0.60 35.0-37.0 Bal.




Specifications

Grade UNS Werkstoff Nr.
Invar 36 K93600 1.3912



Physical Properties

Grade Density Melting Point
Invar 36 8.1 g/cm3 1430°C



Coefficient of Expansion

Alloy Linear Coefficient of Thermal Expansion a,10-6/degree
20-50 20-100 20-200 20-300 20-400 20-500
Invar 36 0.6 0.8 2.0 5.1 8.0 10.0




4j36 Precision Alloy 2





Invar Applied field:



Invar 36 suits for need to apply ultra-low coefficient of heat expansion environment.

Typical applications are as follows:
1.Liquefied gas production, storage and transport

2.The measurement and control instruments work temperature lower than 200°C, such as temperature regulating device
3.Metals and other materials use the screw connector bush
4.Bimetal and bimetallic temperature controller
5.Film framework
6.Shadow mask
7.CRP components of the aviation industry temper Die
8.lower than -200°C the satellite and missile electronic control unit framework
9.The auxiliary tube of the electromagnetic lens in the laser control device



4j36 Precision Alloy 34j36 Precision Alloy 44j36 Precision Alloy 5
