Soft Magnetic 1j79 Permalloy 80 FeNi79 Iron Based Alloys

Product Details

Place of Origin: China

Brand Name: DLX

Model Number: 1j79

Payment & Shipping Terms

Minimum Order Quantity: 2

Price: $25-$40

Packaging Details: Spool package with Carton box, Coil package with polybag

Delivery Time: 5-21 days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 300 tons per month

Get Best Price
Contact Now
Specifications
Highlight:

1j79 Iron Based Alloys

,

Permalloy 80 Fe Alloys

,

FeNi79 Iron Based Alloys

Material::
Ni80%Fe20%
Certificate:
ISO9001
Shape:
Pipe
Ni (Min):
78.5-81.5
Density::
8.4 G/cm3
Size:
Customized
Color:
Nickel,silver
Heating Temp:
1100-1150
Material::
Ni80%Fe20%
Certificate:
ISO9001
Shape:
Pipe
Ni (Min):
78.5-81.5
Density::
8.4 G/cm3
Size:
Customized
Color:
Nickel,silver
Heating Temp:
1100-1150
Description
Soft Magnetic 1j79 Permalloy 80 FeNi79 Iron Based Alloys

Soft Magnetic 1j79 Permalloy 80 FeNi79 Iron Based Alloys 0


Soft Magnetic 1j79 Permalloy 80 FeNi79 Iron Based Alloys 1


  • precision alloy 1J79 Permalloy 80 /FeNi79 pipe/tubes

1J79 (Soft magnetic alloy) precision alloy





precision alloy 1J79  saturation magnetic induction Bs≥0.75T, Curie point ℃ = 450, Resistivity (μΩ • m) = 0.55; precision alloy having small Magnetostrictive coefficient, Easy permeability, Fast demagnetization, small Coercive force, Low eddy loss, be used covering frequency, medium to high frequencies over the entire frequency range, precision alloy Products include: strip, sheet, bar, wire and foil. precision alloy Mainly used for switching power transformers, Precision transformer, Leakage switch transformer, Magnetic shielding, Yoke and weak magnetic field applied high sensitivity small power transformer zero-sequence power transformer, Low-power magnetic amplifiers, high frequency power.





In addition to high permeability, its other magnetic properties are low coercivity, near zero magnetostriction, and significant anisotropic magnetoresistance. precision alloyThe low magnetostriction is critical for industrial applications, allowing it to be used in thin films where variable stresses would otherwise cause a ruinously large variation in magnetic properties. Permalloy's electrical resistivity can vary as much as 5% depending on the strength and the direction of an applied magnetic field. Permalloys typically have the face centered cubic crystal structure with a lattice constant of approximately 0.355 nm in the vicinity of a nickel concentration of 80%. precision alloy A disadvantage of permalloy is that it is not very ductile or workable, so applications requiring elaborate shapes, such as magnetic shields, are made of other high permeability precision alloy  such as mu metal. Permalloy is used in transformer laminations and magnetic recording heads.

precision alloy 1J79 widely used in radio-electronic industry, precision instruments, remote control and automatic control system.





precision alloy precision alloy precision alloy









Chemical composition(%)



Grade C Si Mn P S Ni Cr Mo Fe
1J79 ≤0.03 0.3~0.5 0.6~1.1 ≤0.02 ≤0.02 78.5~80 - 3.8~4.1 Bal.



Physical properties

  • Density (g/cm3): 8.6
  • Curie point (℃): 450
  • Electrical resistivity (μΩ*cm): 55 (20℃)
  • Thermal conductivity ( W/m. ℃): 13.4



Magnetic properties

  • Initial permeability μ0 (mH/m): ≥40
  • Maximum permeability μm (mH/m): ≥310
  • Coercivity Hc (A/m): ≤2.0
  • Saturation magnetic induction Bs (T): 0.73

  • Application
  1. ​​Infrastructure such as bridges, trestles, water towers, wind turbines, pipelines
  2. Marine and offshore applications, such as bridges, hulls for ships and tankers, offshore wind turbines
  3. Corrosion Under Insulation (CUI)
  4. Boilers and Digesters



Soft Magnetic 1j79 Permalloy 80 FeNi79 Iron Based Alloys 2Soft Magnetic 1j79 Permalloy 80 FeNi79 Iron Based Alloys 3Soft Magnetic 1j79 Permalloy 80 FeNi79 Iron Based Alloys 4Soft Magnetic 1j79 Permalloy 80 FeNi79 Iron Based Alloys 5
