0.08mm Thermal Spray Wire with 0.80mm/1.00mm/1.20mm/1.60mm Sizes and 7.14g/cm3 Density for High Performance Coatings

Brand Name:	DLX
Model Number:	Thermal spray wires Pure Zinc wire
MOQ:	10kgs
Price:	USD 3-6/KG
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Surface:

Bright

Size:

0.80mm/1.00mm/1.20mm/1.60mm

Density:

7.14g/cm3

Powder Or Not:

Not Powder

Zn (Min):

99.99%

Packaging Details:

Carton box with pallet, OEM is acceptable

Highlight:

0.08mm Thermal Spray Wire

Hastelloy C276 Alloy

Monel K500 Thermal Spray Wire

Product Description

0.08mm Thermal Spray Wire

Thermal Spray Wire is widely used in arc and flange flame spray systems, offering high corrosion resistance and temperature protection. It creates coatings that resist heat and prevent scaling on conventional low alloy steels, serves as bond coats to improve top coating adhesion, and is used on moulds in the glass industry.

Thermal Spray Wire Series

Inconel 625
45CT
Ni95Al5
Monel 400
Monel K500
Hastelloy C276
Cr20Ni80
Pure zinc wire

Properties & Applications

Our thermal spray wire provides excellent bonding strength. The sprayed layers resist high temperature variations and serve as an effective buffer layer for other spraying alloys. Typical properties include:

Hardness: approximately HRc 22
Maximum working temperature: approximately 800°C
Layer thickness: approximately 0.1-0.15mm

Chemical Composition - Pure Zinc Wire

Thermal Spray Item name	Zn	Cd	Pb	Fe	Cu	Balance Total
Pure zinc wire	≥99.995	≤0.002	≤0.003	≤0.002	≤0.001	0.005

Chemical Composition - Alloy Wires

Element	Inconel 625	Ni95Al5	45CT	Monel 400	Monel K500	HC-276	Cr20Ni80
C	≤0.05	≤0.02	0.01-0.1	≤0.04	≤0.25	≤0.02	≤0.08
Mn	≤0.4	≤0.2	≤0.2	2.5-3.5	≤1.5	≤1.0	≤0.06
Fe	≤1.0	N/A	≤0.5	≤1.0	≤1.0	4.0-7.0	N/A
P	≤0.01	≤0.01	≤0.01	≤0.01	≤0.01	≤0.01	≤0.02
S	≤0.01	≤0.01	≤0.01	≤0.01	≤0.01	≤0.01	≤0.01
Si	≤0.15	≤0.2	≤0.2	≤0.15	≤0.5	≤0.08	0.75-1.6
Cu	N/A	N/A	N/A	rest	27-33	N/A	N/A
Ni	rest	rest	rest	65-67	rest	rest	rest
Al	≤0.4	4-5	N/A	≤0.5	2.3-3.15	N/A	N/A
Ti	≤0.4	0.4-1	0.3-1	2.0-3	0.35-0.85	N/A	N/A
Cr	21.5-23	≤0.2	42-46	N/A	N/A	14.5-16	20-23
Nb	3.5-4.15	N/A	N/A	N/A	N/A	N/A	≤1.0
Mo	8.5-10	N/A	N/A	N/A	N/A	15-17	N/A
Impurities	≤0.5	≤0.5	≤0.5	≤0.5	≤0.5	≤0.5	≤0.5
