0.05mmx0.05mm Nikrothal 80 Wire 12mm NiCr Alloy

Product Details

Place of Origin: China

Brand Name: DLX

Model Number: Ni80Cr20

Payment & Shipping Terms

Minimum Order Quantity: 5

Packaging Details: Spool package with Carton box, Coil package with polybag

Delivery Time: 5-21 days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 300 tons per month

Get Best Price
Contact Now
Specifications
Highlight:

0.05mm NiCr Alloy

,

Nikrothal 80 Wire

,

12mm NiCr Alloy

Material:
Nickel, Chromium
Nickel(Min):
76%
Resistivity:
1.09+/-0.05
Tensile Strength:
637MPA
Elongtation:
≥20%
Application:
Heating, Resistivity
Condition:
Hard / Soft
Sureface:
Bright, Oxided, Acide
Delivery Time:
7-20 Days
Name:
Esistance Heating Flat Wire.
Material:
Nickel, Chromium
Nickel(Min):
76%
Resistivity:
1.09+/-0.05
Tensile Strength:
637MPA
Elongtation:
≥20%
Application:
Heating, Resistivity
Condition:
Hard / Soft
Sureface:
Bright, Oxided, Acide
Delivery Time:
7-20 Days
Name:
Esistance Heating Flat Wire.
Description
0.05mmx0.05mm Nikrothal 80 Wire 12mm NiCr Alloy

0.05mmx0.05mm Nikrothal 80 Wire 12mm NiCr Alloy 0


0.05mmx0.05mm Nikrothal 80 Wire 12mm NiCr Alloy 1


  • NiCr Series

Nickel-chromium, nickel, ferrochrome alloy wire with electric high temperature oxidation resistance, high strength, not soften and a series of advantages. When used in a long time, the same type and the permanent elongation is very small, which is more Cr20Ni80 alloy with excellent comprehensive properties, is to produce high-quality varieties of choice for electric components.



Common Name :

Nikrothal 8,MWS-650,NiCrA,Tophet A,HAI-NiCr 80,Chromel A,Alloy A,Alloy 650,N8,Resistohm 80, Stablohm 650,Nichorme V,Nikrothal 80,OhmAlloy109,Nicrove V, Brightray C, Cronix 80, Chromalloy, Chromel, and Gilphy 80

Ni80Cr20 Nickel-Chromium Nickel alloy resistance heating flat wire, ribbon






  • Nickel-chromium alloy performance tables
Performance material Cr10Ni90 Cr20Ni80 Cr30Ni70 Cr15Ni60 Cr20Ni35 Cr20Ni30
Composition Ni 90 Rest Rest 55.061.0 34.037.0 30.034.0
Cr 10 20.023.0 28.031.0 15.018.0 18.021.0 18.021.0
Fe   ≤1.0 ≤1.0 Rest Rest Rest
Maximum temperature 1300 1200 1250 1150 1100 1100
Meltiing point 1400 1400 1380 1390 1390 1390
Density g/cm3 8.7 8.4 8.1 8.2 7.9 7.9
Resistivity   1.09±0.05 1.18±0.05 1.12±0.05 1.00±0.05 1.04±0.05
μΩ·m,20
Elongation at rupture ≥20 ≥20 ≥20 ≥20 ≥20 ≥20
Specific heat   0.44 0.461 0.494 0.5 0.5
J/g.
Thermal conductivity   60.3 45.2 45.2 43.8 43.8
KJ/m.h
Coefficient of lines expansion   18 17 17 19 19
a×10-6/
(201000℃)
Micrographic structure   Austenite Austenite Austenite Austenite Austenite
Magnetic properties   Nonmagnetic Nonmagnetic Nonmagnetic Weak magnetic Weak magnetic




  • The Form we could offer
Size Range

Wire
dia 0.03-7.5mm
0.05mmx0.05mm Nikrothal 80 Wire 12mm NiCr Alloy 2
dia 8.0-12.0mm
0.05mmx0.05mm Nikrothal 80 Wire 12mm NiCr Alloy 3
Ribbon
(0.05-0.35)*(0.5-6.0)mm
0.05mmx0.05mm Nikrothal 80 Wire 12mm NiCr Alloy 4
Strip
(0.50-2.5)*(5-180)mm
0.05mmx0.05mm Nikrothal 80 Wire 12mm NiCr Alloy 5
Rod
8-50mm

0.05mmx0.05mm Nikrothal 80 Wire 12mm NiCr Alloy 6
