Product Details
Place of Origin: China Jiangsu
Brand Name: DLX
Certification: CE,ROHS
Model Number: Inconel 600 tube
Payment & Shipping Terms
Minimum Order Quantity: 5
Packaging Details: Spool package with Carton box, Coil package with polybag
Delivery Time: 5-20 Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500 tons per month
Material: |
Nickel Chromium Iron |
Nickel(Min): |
72% |
Specific Heat: |
444 J/kg-°C |
Permeability At 200 Oersted (15.9 KA/m): |
1.010 |
Density: |
8.47 G/cm3 |
Condition: |
Hard / Soft |
Sureface: |
Bright,Oxided |
Delivery Time: |
7-50 Days |
Melting Range: |
1354-1413 ℃ |
Material: |
Nickel Chromium Iron |
Nickel(Min): |
72% |
Specific Heat: |
444 J/kg-°C |
Permeability At 200 Oersted (15.9 KA/m): |
1.010 |
Density: |
8.47 G/cm3 |
Condition: |
Hard / Soft |
Sureface: |
Bright,Oxided |
Delivery Time: |
7-50 Days |
Melting Range: |
1354-1413 ℃ |
INCONEL (nickel-chromium-iron) alloy 600 (UNS N06600/W.Nr. 2.4816) is a standard engineering material for applications which require resistance to corrosion and heat. The alloy also has excellent mechanical properties and presents the desirable combination of high strength and good workability. The limiting chemical composition of INCONEL alloy 600 is shown in Table 1. The high nickel content gives the alloy resistance to corrosion by many organic and inorganic compounds and also makes it virtually immune to chloride-ion stress-corrosion cracking. Chromium confers resistance to sulfur compounds and also provides resistance to oxidizing conditions at high temperatures or in corrosive solutions. The alloy is not precipitation hardenable; it is hardened and strengthened only by cold work. The versatility of INCONEL alloy 600 has led to its use in a variety of applications involving temperatures from cryogenic to above 2000°F (1095°C).
| Element | Percent |
| Nickel (plus Cobalt) (Min) | 72 |
| Chromium | 14-17 |
| Iron | 6-10 |
| Carbon (Max) | .15 |
| Manganese (Max) | 1 |
| Sulfur (Max) | .015 |
| Silicon (Max) | .5 |
| Copper (Max) | .5 |
Some typical applications are:
| AMS Number | Alloy | Cross Ref. Spec | Misc./Shape | |
|---|---|---|---|---|
| AMS 5540 Plate | Inconel 600 | - | Plate | |
| AMS 5540 Sheet | Inconel 600 | - | Sheet | |
| AMS 5540 Strip | Inconel 600 | - | Strip | |
| AMS 5580 Custom Tube | Inconel 600 | - | Custom Tube | |
| AMS 5580 Tubing | Inconel 600 | - | Tubing | |
| AMS 5665 Bar | Inconel 600 | - | Bar | |
| AMS 5665 Custom Tube | Inconel 600 | - | Custom Tube | |
| AMS 5665 Ring | Inconel 600 | - | Ring | |
| AMS 5961 | Inconel 600 | - | Wire | |
