637 MPA Nickel Chromium Ni60Cr15 Resistance Wire For Vacuum Electronic Devices

Name: 637 MPA Nickel Chromium Ni60Cr15 Resistance Wire For Vacuum Electronic Devices
Brand: Changzhou DLX Alloy Co., Ltd.
SKU: Ni60Cr15
Price: 35.00 USD
Availability: InStock

Brand Name:	DLX
Model Number:	Ni60Cr15
MOQ:	5
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China Jiangsu

Certification:

CE,ROHS

Material:

Nickel, Chromium

Nickel(Min):

55%

Resistivity:

1.12+/-0.05

Tensile Strength:

637MPA

Elongtation:

≥20%

Application:

Heating, Resistivity

Condition:

Hard / Soft

Sureface:

Bright, Oxided, Acide

Delivery Time:

7-20 Days

Name:

Resistance Heating Wire

Packaging Details:

Spool package with Carton box, Coil package with polybag

Supply Ability:

500 tons per month

Highlight:

Nickel Chromium Ni60Cr15 Resistance Wire

637 MPA Ni60Cr15 Resistance Wire

Ni60Cr15 Resistance Wire

Product Description

637 MPA Nickel Chromium Ni60Cr15 Resistance Wire For Vacuum Electronic Devices 0

Cr15Ni60 Heating Resistance Wire

Ni60Cr15 is kind of high resistivity nicr alloy, which working temperture up to 1150°C. This kind of alloy is characterized by high resistivity, good oxidation resistance, very good form stability, good ductility after use and excellent weldabilit. Ni60Cr15 NiCr alloy wire is used for electric heating elements in industrial appliances.

Electron Beam Emitters

Ni60Cr15 resistance wire is commonly used in electron beam emitters for generating and controlling electron beams. Its high-temperature stability and resistance characteristics enable it to stably generate electron beams in vacuum environments for extended periods, used in various applications such as microwave tubes, electron microscopes, and ion implanters.

Heating Elements

Ni60Cr15 resistance wire is also widely used as heating elements in vacuum electronic devices. In vacuum environments, some components of electronic devices may require heating to function properly, and the high-temperature stability and resistance characteristics of Ni60Cr15 resistance wire make it an ideal heating element material.

Vacuum Sealing

Ni60Cr15 resistance wire can be used in vacuum sealing applications for connecting and sealing components and parts of vacuum electronic devices. Its high-temperature stability and resistance characteristics enable it to provide reliable sealing in vacuum environments, ensuring a stable vacuum environment inside the devices.

Nickel-chromium alloy performance tables

Performance material		Cr10Ni90	Cr20Ni80	Cr30Ni70	Cr15Ni60	Cr20Ni35	Cr20Ni30
Composition	Ni	90	Rest	Rest	55.0～61.0	34.0～37.0	30.0～34.0
	Cr	10	20.0～23.0	28.0～31.0	15.0～18.0	18.0～21.0	18.0～21.0
	Fe	--	≤1.0	≤1.0	Rest	Rest	Rest
Maximum temperature℃		1300	1200	1250	1150	1100	1100
Meltiing point ℃		1400	1400	1380	1390	1390	1390
Density g/cm3		8.7	8.4	8.1	8.2	7.9	7.9
Resistivity		--	1.09±0.05	1.18±0.05	1.12±0.05	1.00±0.05	1.04±0.05
μΩ·m,20℃
Elongation at rupture		≥20	≥20	≥20	≥20	≥20	≥20
Specific heat		--	0.44	0.461	0.494	0.5	0.5
J/g.℃
Thermal conductivity		--	60.3	45.2	45.2	43.8	43.8
KJ/m.h℃
Coefficient of lines expansion		--	18	17	17	19	19
a×10-6/
(20～1000℃)
Micrographic structure		--	Austenite	Austenite	Austenite	Austenite	Austenite
Magnetic properties		--	Nonmagnetic	Nonmagnetic	Nonmagnetic	Weak magnetic	Weak magnetic

637 MPA Nickel Chromium Ni60Cr15 Resistance Wire For Vacuum Electronic Devices 1

The Form we could offer

Size Range
Wire	dia 0.03-7.5mm
	dia 8.0-12.0mm
Ribbon	(0.05-0.35)*(0.5-6.0)mm

Strip	(0.50-2.5)*(5-180)mm

Rod	8-50mm
