Thermal Sensitive Devices Polished Bright Nickel Alloy Ni60Cr15 Resistance Wire

Thermal Sensitive Devices Polished Bright Nickel Alloy Ni60Cr15 Resistance Wire

Brand Name: DLX
Model Number: Ni60Cr15
MOQ: 5
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500 tons per month
Detail Information
Place of Origin:
China Jiangsu
Certification:
CE,ROHS
Material:
Nickel, Chromium
Nickel(Min):
55%
Resistivity:
1.12+/-0.05
Tensile Strength:
637MPA
Elongtation:
≥20%
Application:
Heating, Resistivity
Condition:
Hard / Soft
Sureface:
Bright, Oxided, Acide
Delivery Time:
7-20 Days
Name:
Resistance Heating Wire
Packaging Details:
Spool package with Carton box, Coil package with polybag
Supply Ability:
500 tons per month
Highlight:

Polished Bright Ni60Cr15 Resistance Wire

,

Ni60Cr15 Resistance Wire

,

Thermal Sensitive Devices Ni60Cr15 Resistance Wire

Product Description

Thermal Sensitive Devices Polished Bright Nickel Alloy Ni60Cr15 Resistance Wire 0




  • Cr15Ni60 Heating Resistance Wire

Ni60Cr15 is kind of high resistivity nicr alloy, which working temperture up to 1150°C. This kind of alloy is characterized by high resistivity, good oxidation resistance, very good form stability, good ductility after use and excellent weldabilit. Ni60Cr15 NiCr alloy wire is used for electric heating elements in industrial appliances.


  • Temperature Sensors

Ni60Cr15 resistance wire can be used to manufacture temperature sensors for measuring ambient temperature or surface temperature of objects. Its resistance varies with temperature changes, allowing for precise temperature measurement, widely used in industrial control, meteorological monitoring, and laboratory research.

  • Thermistors

Ni60Cr15 resistance wire can also be used to manufacture thermistors, whose resistance varies with temperature changes. These thermistors serve as temperature-sensitive components in circuits, used for temperature measurement, temperature compensation, and temperature control applications.

  • Temperature Controllers

Utilizing the temperature-responsive characteristics of Ni60Cr15 resistance wire, temperature controllers can be manufactured for controlling the temperature in heating or cooling systems. These temperature controllers are widely used in household appliances, industrial equipment, and medical devices.

  • Thermal-sensitive Components

The thermal-sensitive properties of Ni60Cr15 resistance wire make it an ideal material for thermal-sensitive components used in various applications requiring temperature sensing and control, such as temperature alarms, thermostats, and temperature monitoring systems.


  • Nickel-chromium alloy performance tables
Performance material Cr10Ni90 Cr20Ni80 Cr30Ni70 Cr15Ni60 Cr20Ni35 Cr20Ni30
Composition Ni 90 Rest Rest 55.061.0 34.037.0 30.034.0
Cr 10 20.023.0 28.031.0 15.018.0 18.021.0 18.021.0
Fe -- ≤1.0 ≤1.0 Rest Rest Rest
Maximum temperature 1300 1200 1250 1150 1100 1100
Meltiing point 1400 1400 1380 1390 1390 1390
Density g/cm3 8.7 8.4 8.1 8.2 7.9 7.9
Resistivity -- 1.09±0.05 1.18±0.05 1.12±0.05 1.00±0.05 1.04±0.05
μΩ·m,20
Elongation at rupture ≥20 ≥20 ≥20 ≥20 ≥20 ≥20
Specific heat -- 0.44 0.461 0.494 0.5 0.5
J/g.
Thermal conductivity -- 60.3 45.2 45.2 43.8 43.8
KJ/m.h
Coefficient of lines expansion -- 18 17 17 19 19
a×10-6/
(201000℃)
Micrographic structure -- Austenite Austenite Austenite Austenite Austenite
Magnetic properties -- Nonmagnetic Nonmagnetic Nonmagnetic Weak magnetic Weak magnetic



Thermal Sensitive Devices Polished Bright Nickel Alloy Ni60Cr15 Resistance Wire 1Thermal Sensitive Devices Polished Bright Nickel Alloy Ni60Cr15 Resistance Wire 2




















































  • The Form we could offer
Size Range

Wire
dia 0.03-7.5mm
Thermal Sensitive Devices Polished Bright Nickel Alloy Ni60Cr15 Resistance Wire 3
dia 8.0-12.0mm
Thermal Sensitive Devices Polished Bright Nickel Alloy Ni60Cr15 Resistance Wire 4
Ribbon
(0.05-0.35)*(0.5-6.0)mm
Thermal Sensitive Devices Polished Bright Nickel Alloy Ni60Cr15 Resistance Wire 5
Strip
(0.50-2.5)*(5-180)mm
Thermal Sensitive Devices Polished Bright Nickel Alloy Ni60Cr15 Resistance Wire 6
Rod
8-50mm

Thermal Sensitive Devices Polished Bright Nickel Alloy Ni60Cr15 Resistance Wire 7
