Good Forming Performance Ni70Cr30 Wire with 637MPa Tensile Strength and ≥20% Elongation for Medical Devices

Name: Good Forming Performance Ni70Cr30 Wire with 637MPa Tensile Strength and ≥20% Elongation for Medical Devices
Brand: Changzhou DLX Alloy Co., Ltd.
SKU: Ni70Cr30
Price: 35.00 USD
Availability: InStock

Brand Name:	DLX
Model Number:	Ni70Cr30
MOQ:	5
Payment Terms:	L/C,T/T,Western Union,MoneyGram
Supply Ability:	500 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China Jiangsu

Certification:

CE,ROHS

Material:

Nickel, Chromium

Nickel(Min):

66%

Resistivity:

1.18+/-0.05

Tensile Strength:

637MPA

Elongtation:

≥20%

Application:

Heating, Resistivity

Condition:

Hard / Soft

Sureface:

Bright, Oxided, Acide

Delivery Time:

7-20 Days

Name:

Resistance Heating Wire

Packaging Details:

Spool package with Carton box, Coil package with polybag

Supply Ability:

500 tons per month

Highlight:

Medical Devices Nickel Chrome Wire

Good Forming Performance Nickel Chrome Wire

Nickel Chrome 70/30 Ni70Cr30 Wire

Product Description

Good Forming Performance Nickel Chrome 70/30 Ni70Cr30 Wire For Medical Devices

Ni70Cr30 is an austenitic nickel-chromium alloy suitable for temperature applications up to 1250°C. High chromium content (30% in average) provides very good life time, especially in furnace applications.

Ni70Cr30 is characterized by high resistivity, good oxidation resistance, good ductility after use and excellent weldability. The alloy is not subject to "green rot" and is particularly well suited for reducing and oxidizing atmospheres.

Medical Applications

Surgical Electrosurgical Knife: Commonly used to generate high temperatures for tissue cutting with stable high-temperature performance and conductivity.
High-temperature Sterilization Equipment: Used to generate high temperatures for sterilizing medical instruments and equipment.
Medical Imaging Equipment: Used in heating elements of X-ray tubes and CT scanners to ensure normal operation and imaging quality.
Bioreactors: Used for temperature control to simulate and control temperature conditions for biological reactions.
Medical Aesthetic Devices: Used as heating elements in high-frequency electrotherapy devices for skin treatments.

Nickel-Chromium Alloy Performance Comparison

Performance material	Cr10Ni90	Cr20Ni80	Cr30Ni70	Cr15Ni60	Cr20Ni35	Cr20Ni30
Composition Ni	90	Rest	Rest	55.0～61.0	34.0～37.0	30.0～34.0
Cr	10	20.0～23.0	28.0～31.0	15.0～18.0	18.0～21.0	18.0～21.0
Fe	--	≤1.0	≤1.0	Rest	Rest	Rest
Maximum temperature℃	1300	1200	1250	1150	1100	1100
Meltiing point ℃	1400	1400	1380	1390	1390	1390
Density g/cm3	8.7	8.4	8.1	8.2	7.9	7.9
Resistivity μΩ·m,20℃	--	1.09±0.05	1.18±0.05	1.12±0.05	1.00±0.05	1.04±0.05
Elongation at rupture	≥20	≥20	≥20	≥20	≥20	≥20
Specific heat J/g.℃	--	0.44	0.461	0.494	0.5	0.5
Thermal conductivity KJ/m.h℃	--	60.3	45.2	45.2	43.8	43.8
*Coefficient of lines expansion a10-6/(20～1000℃)**	--	18	17	17	19	19
Micrographic structure	--	Austenite	Austenite	Austenite	Austenite	Austenite
Magnetic properties	--	Nonmagnetic	Nonmagnetic	Nonmagnetic	Weak magnetic	Weak magnetic

Available Forms and Sizes

Size Range	Visual Reference
Wire dia 0.03-7.5mm
Wire dia 8.0-12.0mm
Ribbon (0.05-0.35)*(0.5-6.0)mm
Strip (0.50-2.5)*(5-180)mm
Rod 8-50mm
