Ni30Cr20 Nickel Chromium Heating Wire with Resistivity 1.04+/-0.05, Tensile Strength 637MPA, and Elongation ≥20%

Name: Ni30Cr20 Nickel Chromium Heating Wire with Resistivity 1.04+/-0.05, Tensile Strength 637MPA, and Elongation ≥20%
Brand: Changzhou DLX Alloy Co., Ltd.
SKU: Ni30Cr20
Price: 35.00 USD
Availability: InStock

Brand Name:	DLX
Model Number:	Ni30Cr20
MOQ:	5
Payment Terms:	L/C,T/T,Western Union,MoneyGram
Supply Ability:	500 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China Jiangsu

Certification:

CE,ROHS

Material:

Nickel, Chromium

Nickel(Min):

30%

Resistivity:

1.04+/-0.05

Tensile Strength:

637MPA

Elongtation:

≥20%

Application:

Heating, Resistivity

Condition:

Hard / Soft

Sureface:

Bright, Oxided, Acide

Delivery Time:

7-20 Days

Name:

Resistance Heating Wire

Packaging Details:

Spool package with Carton box, Coil package with polybag

Supply Ability:

500 tons per month

Highlight:

Ni30Cr20 Heating Wire

Resistors Ni30Cr20 Heating Wire

Nickel Chrome Ni30Cr20 Heating Wire

Product Description

SWG18 Swg19 Nickel Chrome 30/20 Wire Ni30Cr20 Heating Wire Used For Resistors

Cr20Ni30 Heating Resistance Wire is an austenitic nickel-chromium alloy suitable for temperature applications up to 1100°C. This alloy features high resistivity, excellent oxidation resistance, good post-use ductility, and superior weldability. Ni35Cr20 is widely used in electric heating elements for domestic appliances.

Applications

Resistor Adjusters: Cr20Ni30 resistance wire regulates resistance values in circuits to control current or voltage magnitude, commonly used in dimmers and speed controllers.
Current Limiters: Serves as a key component to generate appropriate resistance and protect circuits from overload damage.
Resistor Networks: Used in constructing resistor networks for signal conditioning, filtering, and impedance matching applications.
Sensors and Measurement Equipment: Functions as a critical component in resistance-based sensors for measuring temperature, pressure, and humidity with high accuracy and reliability.

Nickel-Chromium Alloy Performance Comparison

Performance Material	Cr10Ni90	Cr20Ni80	Cr30Ni70	Cr15Ni60	Cr20Ni35	Cr20Ni30
Composition Ni	90	Rest	Rest	55.0～61.0	34.0～37.0	30.0～34.0
Cr	10	20.0～23.0	28.0～31.0	15.0～18.0	18.0～21.0	18.0～21.0
Fe	--	≤1.0	≤1.0	Rest	Rest	Rest
Maximum Temperature℃	1300	1200	1250	1150	1100	1100
Melting Point ℃	1400	1400	1380	1390	1390	1390
Density g/cm3	8.7	8.4	8.1	8.2	7.9	7.9
Resistivity μΩ·m,20℃	--	1.09±0.05	1.18±0.05	1.12±0.05	1.00±0.05	1.04±0.05
Elongation at Rupture	≥20	≥20	≥20	≥20	≥20	≥20

Available Forms

Size Range	Image
Wire dia 0.03-7.5mm
Wire dia 8.0-12.0mm
Ribbon (0.05-0.35)*(0.5-6.0)mm
Strip (0.50-2.5)*(5-180)mm
Rod 8-50mm
