Chemical Equipment Resistance Winding Cr20Ni80 Spiral Coil Heating Wire

Brand Name:	DLX
Model Number:	Ni80Cr20
MOQ:	5
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

China Jiangsu

Certification:

CE,ROHS

Material:

Nickel, Chromium

Nickel(Min):

76%

Resistivity:

1.09+/-0.05

Tensile Strength:

637MPA

Elongtation:

≥20%

Application:

Heating, Resistivity

Condition:

Hard / Soft

Sureface:

Bright, Oxided, Acide

Delivery Time:

7-20 Days

Name:

Resistance Heating Wire

Packaging Details:

Spool package with Carton box, Coil package with polybag

Supply Ability:

500 tons per month

Highlight:

Cr20Ni80 Resistance Heating Wire

Chemical Equipment Resistance Heating Wire

Spiral Coil Resistance Heating Wire

Product Description

Chemical Equipment Resistance Winding Cr20Ni80 Spiral Coil Heating Wire 0

Cr20ni80 Heating Resistance Wire

In resistance heaters, Cr20Ni80 resistance wire is a commonly used heating element material. It is composed of 20% chromium and 80% nickel, with excellent electrical resistance characteristics and high temperature stability, suitable for various heating applications.

Corrosion Resistance

Cr20Ni80 resistance wire exhibits excellent corrosion resistance, capable of withstanding corrosion from various aggressive media in chemical equipment, including acids, alkalis, and salts.

High Temperature Resistance

The resistance wire can work stably at high temperatures for prolonged periods, maintaining its resistance characteristics and mechanical properties, suitable for heating and temperature control in high-temperature chemical processes.

Chemical Stability

Cr20Ni80 resistance wire possesses good chemical stability, resistant to the effects of chemical substances, making it suitable for long-term use in chemical equipment.

Uniform Heating

Using Cr20Ni80 resistance wire as heating elements in chemical equipment ensures uniform temperature distribution, ensuring process stability and quality.

Application Areas

1. Cr20Ni80 resistance wire is commonly used in heaters, heating jackets, heating tubes, and other components in chemical equipment, used for heating reactors, evaporators, dryers, and other equipment.
2. In chemical production processes, the widespread application of Cr20Ni80 resistance wire plays a vital role in improving production efficiency and product quality.

Nickel-chromium alloy performance tables

Performance material		Cr10Ni90	Cr20Ni80	Cr30Ni70	Cr15Ni60	Cr20Ni35	Cr20Ni30
Composition	Ni	90	Rest	Rest	55.0～61.0	34.0～37.0	30.0～34.0
	Cr	10	20.0～23.0	28.0～31.0	15.0～18.0	18.0～21.0	18.0～21.0
	Fe	--	≤1.0	≤1.0	Rest	Rest	Rest
Maximum temperature℃		1300	1200	1250	1150	1100	1100
Meltiing point ℃		1400	1400	1380	1390	1390	1390
Density g/cm3		8.7	8.4	8.1	8.2	7.9	7.9
Resistivity		--	1.09±0.05	1.18±0.05	1.12±0.05	1.00±0.05	1.04±0.05
μΩ·m,20℃
Elongation at rupture		≥20	≥20	≥20	≥20	≥20	≥20
Specific heat		--	0.44	0.461	0.494	0.5	0.5
J/g.℃
Thermal conductivity		--	60.3	45.2	45.2	43.8	43.8
KJ/m.h℃
Coefficient of lines expansion		--	18	17	17	19	19
a×10-6/
(20～1000℃)
Micrographic structure		--	Austenite	Austenite	Austenite	Austenite	Austenite
Magnetic properties		--	Nonmagnetic	Nonmagnetic	Nonmagnetic	Weak magnetic	Weak magnetic

Chemical Equipment Resistance Winding Cr20Ni80 Spiral Coil Heating Wire 1

The Form we could offer

Size Range
Wire	dia 0.03-7.5mm
	dia 8.0-12.0mm
Ribbon	(0.05-0.35)*(0.5-6.0)mm

Strip	(0.50-2.5)*(5-180)mm

Rod	8-50mm
