Seawater Pump Components Chemical Processing Industry Monel 400 Wires

Product Details

Place of Origin: China

Brand Name: DLX

Model Number: Monel 400

Payment & Shipping Terms

Minimum Order Quantity: 5

Price: $30-$50

Packaging Details: Spool package with Carton box, Coil package with polybag for monel 400 wire

Delivery Time: 5-21 days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 300 tons per month

Get Best Price
Contact Now
Specifications
Highlight:

Industry Monel 400 Wires

,

Seawater Pump Monel 400 Wires

,

Chemical Processing Industry Monel Wires

Material:
Nickel Copper
Nickel(Min):
63%
Curie Temperature:
21-49℃
Density:
8.05g/cm3
Application:
Anti-corrosion
Condition:
Hard / Soft
Sureface:
Bright,Oxided
Delivery Time:
7-50 Days
Melting Point:
1288-1343℃
Name:
Monel 400 Wire
Material:
Nickel Copper
Nickel(Min):
63%
Curie Temperature:
21-49℃
Density:
8.05g/cm3
Application:
Anti-corrosion
Condition:
Hard / Soft
Sureface:
Bright,Oxided
Delivery Time:
7-50 Days
Melting Point:
1288-1343℃
Name:
Monel 400 Wire
Description
Seawater Pump Components Chemical Processing Industry Monel 400 Wires

Seawater Pump Components Chemical Processing Industry Monel 400 Wires 0

Seawater Pump Components Chemical Processing Industry Monel 400 Wires


Seawater Pump Components Chemical Processing Industry Monel 400 Wires 1

  • Monel Series

Monel 400 wire is a product made from a nickel-copper alloy, known for its excellent corrosion resistance and high strength. It is commonly used in the manufacturing of marine engineering equipment, chemical processing equipment, aerospace components, and other applications requiring corrosion resistance and high strength. Monel 400 wire is available in various diameters and gauges to meet the needs of different customers, widely used in multiple industries.




  • Chemical Properties of Monel 400

Ni Cu Al Ti C Mn Fe S Si
63.0-70.0 27-33 2.30-3.15 0.35-0.85 0.25 max 1.5 max 2.0 max 0.01 max 0.50 max



Seawater Pump Components Chemical Processing Industry Monel 400 Wires 2

  • Mechanical Properties

Product Form Condition Tensile (ksi) .2% Yield (ksi) Elongation % Hardness
Rod & Bar Hot-Finished/Aged 140-190 100-150 30-20 27-38 HRC
Rod & Bar Hot Finished/Annealed 90-110 40-60 45-25 75-90 HRB
Rod & Bar Hot Finished/Annealed/Aged 130-165 85-120 35-20 24-35 HRC
Rod & Bar Cold-Drawn/Aged 135-185 95-160 30-15 25-41 HRC
Rod & Bar Cold-Drawn/Annealed/Aged 130-190 85-120 30-20 24-35 HRC
Plate ot-Finished/Aged 140-180 100-135 30-20 27-37 HRC
Sheet Cold-Rolled/Annealed 90-105 40-65 45-25 85 HRB Max


  • Application

1. Marine Engineering: Monel 400 wire is commonly used in the manufacturing of marine engineering equipment such as seawater desalination units, seawater pumps, and offshore oil pipelines, highly favored for its resistance to seawater corrosion.

2. Chemical Industry: Due to its corrosion resistance to various chemicals, Monel 400 wire is widely employed in the chemical industry for manufacturing chemical reactors, piping for acidic environments, and chemical equipment.

3. Aerospace Industry: Monel 400 wire is also utilized in the aerospace sector for fabricating components of aircraft and spacecraft, including engine parts, structural brackets, and hydraulic systems.

4. Marine Vessels: In the marine vessel sector, Monel 400 wire finds extensive use in the manufacturing of ship equipment and components such as hull structures, marine valves, and pipe fittings, to withstand corrosion from seawater and the marine environment.

5. Chemical Processing: Monel 400 wire is also commonly used in chemical processing and fine chemical industries for manufacturing corrosion-resistant equipment and piping systems, including chlorine processing units and petroleum processing equipment.

Seawater Pump Components Chemical Processing Industry Monel 400 Wires 3

Seawater Pump Components Chemical Processing Industry Monel 400 Wires 4Seawater Pump Components Chemical Processing Industry Monel 400 Wires 5
